Blackmagic Design Ultimatte 12 HD Mini – HD Compositing Processor
Product Overview
The Blackmagic Design Ultimatte 12 HD Mini is a compact real-time compositing processor for keying live-action video, adding HDMI connectivity to the Ultimatte 12's advanced algorithms, improved spill suppression, color science, and color fidelity. It works in HD up to 1080p60 with sub-pixel processing, with one-touch auto-keying and realistic augmented-reality layers in a 1/3-rack chassis.
Product Description
Designed for news, sports, film and television, and entertainment production, the Ultimatte 12 HD Mini creates life-like composites using fixed cameras, static backgrounds, or virtual-set systems, and can layer augmented-reality objects so talent can pre-visualize virtual sets while shooting against green screen. Its HDMI inputs make it easy to connect HDMI cameras and computers, and an SDI monitor input allows cascading. New technology applies accurate keying parameters per camera, and a "realistic" layer mode adds translucent or tinted objects on top of the foreground.
One-touch keying sets over 100 parameters automatically once the set is well lit and white-balanced, dramatically reducing the time to pull a key. Advanced image processing and a large color space generate internal mattes for fine hair detail and smooth transitions, while refined flare and edge processing preserve colors you want to keep. Connections include two HDMI inputs and an HDMI output up to 1080p60, plus SDI and HDMI program and monitor outputs and a 3G-SDI monitor input for cascade. It requires the free Ultimatte Software Control for Mac/Windows and works with the Ultimatte Smart Remote 4, in a 1 RU, 1/3-rack-width chassis.
Key Features
- Up to 1080p60 via HDMI — Easy connection of HDMI sources.
- 1-touch keying — Auto-sets 100+ parameters for a fast, clean key.
- SDI monitor in for cascade — Chain multiple units for monitoring.
- 2× HDMI inputs — Plus SDI and HDMI program and monitor outputs.
- Augmented reality — Realistic translucent and tinted layer compositing.
- Advanced image processing — Fine hair detail and high color fidelity.
- Smart Remote 4 — Optional hardware control panel.
- 1 RU, 1/3-rack — Smallest Ultimatte 12 model.
Typical Applications
- Broadcast studio — Compact HD keying for news, weather, and sports.
- House of worship — Real-time compositing for streamed and projected services.
- Auditorium — HDMI-based virtual environments and presentation.
Technical Specifications
| Model | ULTMKEY12/A/HDM |
| Video I/O | 2× HDMI in, 1× HDMI out; 1× 3G-SDI in, 2× 3G-SDI out, 1× 3G-SDI monitor out |
| Max Resolution | 1080p60 |
| SDI Support | SD/HD/3G-SDI monitor in for cascade |
| USB | 1× USB-C 3.x |
| Control | Ultimatte Software Control (Mac/Windows); Ultimatte Smart Remote 4 |
| Power | 100–240V AC; 12 W |
| Form Factor | 1 RU, 1/3-rack; 2.56 lb / 1.16 kg |
FAQ
How does the HD Mini differ from the HD, 4K, and 8K? The HD Mini adds HDMI I/O at up to 1080p60 in the smallest chassis; the HD uses 3G-SDI, while the 4K and 8K scale to Ultra HD and 8K over 12G-SDI.
Can I cascade units for monitoring? Yes — the 3G-SDI monitor input supports cascading multiple processors.
Does it need a control panel? It requires the free Ultimatte Software Control for Mac/Windows; the Ultimatte Smart Remote 4 is optional.
What sources can it take? Two HDMI inputs up to 1080p60, with SDI and HDMI program and monitor outputs.
