Blackmagic Design HyperDeck Studio HD Pro – HD Rack Recorder
Product Overview
The Blackmagic Design HyperDeck Studio HD Pro is a broadcast-grade deck for recording and playback of HD video up to 1080p60, built around fast SSD media and 12G-SDI connectivity. The 2U rackmount unit pairs dual 12G-SDI and HDMI in/out with a built-in LCD touchscreen, Ethernet and RS-422 control, and dual redundant power, making it suited to studios and live-production racks that need reliable HD recording and playout.
Product Description
This rackmount recorder captures and plays HD video to SSD media, recording in ProRes, DNxHD, and uncompressed formats. It has two 12G-SDI inputs and two 12G-SDI outputs plus HDMI in and out for monitoring and switching, and records to internal SSD or external drives over USB-C. A front LCD touchscreen handles control and monitoring, with Ethernet and RS-422 for remote operation and deck control. Dual redundant, hot-swappable power supplies provide the reliability expected in broadcast environments. The 2U chassis fits a standard equipment rack.
Key Features
- HD up to 1080p60 — Recording and playback to SSD media.
- 12G-SDI and HDMI — Two 12G-SDI in and out, plus HDMI in and out.
- Pro codecs — ProRes, DNxHD, and uncompressed.
- SSD media — Internal SSD or external drives over USB-C.
- Touchscreen control — Built-in LCD, plus Ethernet and RS-422.
- Redundant power — Dual hot-swappable power supplies.
- 2U rackmount — Fits a standard broadcast rack.
Typical Applications
- Broadcast studio — HD recording and playout in a rack-based production chain.
- Auditorium — Capturing or replaying HD program feeds for live events.
- House of worship — Reliable HD recording with redundant power.
Technical Specifications
| Model | HYPERD/ST/DFHP |
| Video Inputs | 2× 12G-SDI; 1× HDMI |
| Video Outputs | 2× 12G-SDI; 1× HDMI |
| Max Resolution | 1080p60 |
| Recording Media | SSD (internal / external via USB-C) |
| Codecs | ProRes, DNxHD, uncompressed |
| Control | LCD touchscreen; Ethernet; RS-422 |
| Power | Dual redundant, hot-swappable |
| Form Factor | 2U rackmount |
FAQ
How is this different from the Studio 4K Pro? The HD Pro records up to 1080p60; the Studio 4K Pro shares the same I/O and form factor but records up to 2160p60 (UHD).
What media does it record to? SSD media, either internal or external over USB-C.
Which codecs does it support? ProRes, DNxHD, and uncompressed.
Is the power redundant? Yes — dual hot-swappable power supplies.
