Blackmagic Design Camera Fiber Converter - CINEURSANWFRCAM
Product Overview
The Blackmagic Design Camera Fiber Converter attaches to a URSA Broadcast camera to connect it to studio infrastructure over a single SMPTE fiber-optic cable, pairing with a separately available Studio Fiber Converter for runs up to 1.6 miles. It relocates common camera controls to the rear of the camera for operator access and adds studio-standard connections including a 5-pin XLR talkback headset port and SDI monitoring, carrying HD or 4K over one outgoing 12G-SDI link with three incoming 3G-SDI feeds.
Key Specs
- Connects URSA Broadcast to studio infrastructure over SMPTE fiber
- Pairs with a separately sold Studio Fiber Converter (up to 1.6 miles)
- 1x outgoing 12G-SDI, 3x incoming 3G-SDI return feeds
- 5-pin XLR talkback headset ports
- Relocates common camera controls to the camera rear
Product Description
Secure the Blackmagic Design Camera Fiber Converter to your URSA Broadcast camera to interface with studio infrastructure via SMPTE fiber optic cable and a separately available Studio Fiber Converter for breakout up to 1.6 miles away. The converter moves the most common camera controls to the rear of the camera assembly for ease of operator access. Studio-standard connectivity includes talkback headset 5-pin XLR ports, as well as SDI video for monitor output. In total, the Camera Fiber Converter has a single outgoing 12G-SDI connection for HD or UHD 4K video and three incoming 3G-SDI connections for monitoring with a separate studio viewfinder. Use the V-lock at the top to secure the studio viewfinder. All mounting hardware is included for securing the converter to the camera.
Features
- For URSA Broadcast
- Full Studio Connectivity
- SMPTE Fiber Interface
- 12G-SDI Output
- 3 x 3G-SDI Return Feeds
- 5-Pin XLR Talkback Headset Connections
- Camera Controls Moved to Camera Rear
Specification
Blackmagic Design CINEURSANWFRCAM Specs
| Connections | SMPTE Optical Fiber: 1 x SMPTE 304 12G-SDI Input: 1 x BNC 12G-SDI Output: 1 x BNC 3G-SDI Return Output: 3 x BNC Talkback Headset: 2 x 5-pin XLR Analog Audio Input: 2 x XLR (AES/mic/line) Computer: 1 x USB Type-C |
| Video Standards | 3840 x 2160: 60/59.94/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.9 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
| SDI Standards | SMPTE 259M, SMPTE 292M, 296M, 372M, 424M Level B, 425M |
| Audio Sampling | 24-bit, 48 kHz |
| Video Sampling | 4:2:2 |
| Bit Depth | 10-bit |
| Color Space | REC 709, REC 2020 |
| Dimensions | 7.5 x 5.5 x 5.4" / 19.1 x 14 x 13.8 cm |
| Weight | 4.9 lb / 2.2 kg |
| Package Weight | 5.875 lb |
| Box Dimensions (LxWxH) | 10.35 x 8.45 x 8.15" |
Frequently Asked Questions
What camera is it for?
The Blackmagic URSA Broadcast camera.
Is the Studio Fiber Converter included?
No, it is required and sold separately to break out the signals at the studio end.
How far can the fiber run?
Up to 1.6 miles over a single SMPTE fiber cable.
