Blackmagic Design URSA Mini Pro 12K OLPF – Super 35 Cinema Camera

Product Overview

The Blackmagic Design URSA Mini Pro 12K OLPF is the optical-low-pass-filter version of the URSA Mini Pro 12K, built around the same 12,288×6480 (80MP) Super 35 sensor with 14 stops of dynamic range, Generation 5 Color Science, and RGBW design. The OLPF is precisely matched to the 12K sensor for better detail handling and reduced moiré — particularly valuable for high-end feature film and virtual production on LED walls.

Product Description

This OLPF model adds a high-performance optical low-pass filter to the URSA Mini Pro 12K. In virtual production environments, the high frequencies of an LED video wall can interfere with ultra-sharp lenses and high-resolution sensors, creating moiré and aliasing; the matched OLPF minimizes that interference, and its updated IR filtering improves far-red color response for higher image fidelity. Otherwise the camera is identical to the standard 12K: a native 12,288×6480 Super 35 sensor at 80MP per frame, 14 stops of dynamic range, in-sensor scaling for 8K and 4K RAW without changing field of view, and frame rates up to 60 fps in 12K, 110 fps in 8K, and 220 fps in 4K Super 16. It records 12-bit Blackmagic RAW to dual CFast and UHS-II SD cards or external SSDs via a 10 Gb/s USB-C port, features an interchangeable PL mount and built-in ND filters, runs Blackmagic OS, and includes DaVinci Resolve Studio.

Key Features

• 12K Super 35 sensor with OLPF — Optical low-pass filter matched to the sensor.
• Reduced moiré & aliasing — Ideal for LED-wall virtual production.
• Improved IR / far-red color — Updated IR filtering for higher fidelity.
• 80MP per frame, 14 stops — 12,288×6480 native resolution.
• High frame rates — 12K to 60 fps, 8K to 110 fps, 4K Super 16 to 220 fps.
• Interchangeable PL mount & ND filters — Built-in precision ND wheel.
• Dual CFast + UHS-II SD + USB-C — 12-bit Blackmagic RAW recording.
• DaVinci Resolve Studio included — Full post-production suite.

Technical Specifications

FAQ

What does the OLPF add over the standard URSA Mini Pro 12K? An optical low-pass filter matched to the 12K sensor that reduces moiré and aliasing — especially with LED video walls — and updated IR filtering for better far-red color.

Is the sensor the same as the standard 12K? Yes — the same 12,288×6480 Super 35 sensor, 14 stops, Generation 5 Color Science; only the OLPF is added.

Which lens mounts work? An interchangeable PL mount ships standard; EF and F mounts are available separately.

What software is included? A full version of DaVinci Resolve Studio.
