Black Box LPS535A-SFP – Gigabit PoE+ Media Converter SFP

Product Overview

The Black Box LPS535A-SFP is a Gigabit Ethernet PoE+ media converter with an SFP slot for flexible fiber or copper uplink selection. Designed for commercial network deployments, it extends IEEE 802.3at PoE+ power delivery over fiber runs where copper infrastructure is impractical. AV integrators and IT teams use this converter to connect PoE-dependent devices — IP cameras, VoIP phones, wireless access points — across fiber backbone segments without adding a separate power injector.

Product Description

The LPS535A-SFP bridges 10/100/1000BASE-T copper networks with fiber optic infrastructure using a user-selectable SFP transceiver module. The device delivers up to 30W of IEEE 802.3at PoE+ power on the copper RJ-45 port, making it well-suited for powering PTZ cameras, 802.11ac access points, and other high-draw PoE endpoints across extended fiber runs. The SFP slot accepts standard LC-interface modules for multimode or single-mode fiber, giving integrators the flexibility to match existing plant infrastructure without rewiring. The converter operates in standalone mode with no management software required, simplifying deployment in wiring closets, above-ceiling enclosures, and remote distribution points. Auto-negotiation on the copper port handles speed and duplex selection automatically. The compact form factor and wide operating temperature range suit both conditioned and semi-conditioned spaces. For comparable fiber media converters and networking infrastructure products, visit creationnetworks.net.

Key Features

• IEEE 802.3at PoE+ Output — Delivers up to 30W on the RJ-45 port to power high-draw PoE devices without a separate injector.
• SFP Slot for Flexible Fiber Selection — Accepts standard SFP transceivers for multimode or single-mode fiber, matching any existing fiber plant.
• Gigabit Ethernet Speed — 10/100/1000BASE-T auto-negotiating copper port supports full bandwidth for HD video and data traffic.
• Standalone Operation — No management software or configuration required; plug-and-play deployment in closets and distribution points.
• Auto-Negotiation — Automatic speed and duplex detection on the copper side eliminates manual configuration.
• Compact Form Factor — Small enclosure fits in tight wiring spaces, above-ceiling mounts, and rack-adjacent positions.
• Wide Compatibility — Works with standard SFP modules from major vendors for multimode 850nm or single-mode 1310/1550nm fiber optic links.
