Biamp Desono SUB2400 Passive 2 x 10" subwoofer, 4 ohms or 16 ohms / 600 watts, plywood construction with structured paint, pole mount adaptor (Black) - 911.1493.900
Biamp Desono SUB2400 Passive 2 x 10" subwoofer, 4 ohms or 16 ohms / 600 watts, plywood construction with structured paint, pole mount adaptor (Black) - 911.1493.900 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Biamp Desono SUB2400 Passive 2 x 10" subwoofer, 4 ohms or 16 o...
Product Overview
The Biamp Desono SUB2400 is a powerful passive dual 10-inch subwoofer, supplied in black. It is designed to deliver punchy bass for venues that often require dance-level music, such as bars, pubs, clubs, restaurants, and taverns. It pairs well with MASK6 or MASK8 cabinet loudspeakers and a digital amplifier to form a complete sound system. The SUB2400 is intended for permanent indoor installations.
Product Description
The SUB2400 uses two band-pass chambers, each equipped with a 10-inch dual-coil woofer. Combined with push-pull technology, this produces a relatively small cabinet with high output and low distortion, and the small woofers move less mass for punchy, fast bass reproduction. The subwoofer can be driven in 4-ohm or 16-ohm mode, selected by a switch on the rear panel; the 16-ohm mode is advised for long cable runs and allows multiple cabinets to be used. It handles 600W and is built from plywood with a structured paint finish. It is supplied in black.
Key Features
- Push-Pull Band-Pass Design — Two band-pass chambers with dual-coil woofers in a push-pull configuration deliver high output with low distortion.
- Punchy Bass — The small dual 10-inch woofers move less mass for fast, punchy bass reproduction.
- Switchable Impedance — A rear rocker switch selects 4-ohm or 16-ohm operation.
- Multi-Cabinet Capable — The 16-ohm mode reduces loss on long cable runs and allows multiple cabinets to be used.
- 600W Power Handling — The subwoofer handles 600W continuous at 4 ohms.
Typical Applications
- Multi-purpose room
- Commercial meeting space
- Auditorium
Technical Specifications
| Operating Mode | Passive |
| Operating Environment | Indoor |
| Operating Range (-3dB) | 45 Hz to 150 Hz |
| Nominal Beamwidth (H x V) | Omnidirectional |
| Transducers | LF 2 x 10-inch (254 mm) treated paper cones |
| Continuous Power Handling | 600W @ 4Ω (2400W peak) |
| Nominal Sensitivity @ 1m | 99 dB (1W); 99 dB (2.83V) |
| Nominal Maximum SPL @ 1m | 133 dB peak; 127 dB continuous |
| Recommended Amplifiers | 250W - 750W @ 4Ω (49V - 69V) |
| Input Connection | 2 Speakon-compatible connectors wired in parallel |
| Controls | Rocker switch for 4Ω or 16Ω operation |
| Environmental | IP20 per IEC 60529 |
| Dimensions (H x W x D) | 27.6 in x 13.8 in x 17.7 in (700 x 350 x 450 mm) |
| Weight | 64.4 lbs (29.2 kg) |
| Finish | Plywood, matte finish, Black |
Frequently Asked Questions
What impedance does the SUB2400 run at?
It can be driven in 4-ohm or 16-ohm mode, selected by a switch on the rear panel.
Why use the 16-ohm mode?
The 16-ohm mode reduces power loss on long cable runs and allows multiple cabinets to be connected.
What loudspeakers pair with it?
It is designed to pair with MASK6 or MASK8 cabinet loudspeakers and a digital amplifier.
