Biamp Desono EX-S10SUB-UB 10” Subwoofer Surface Mount Indoor/Outdoor Loudspeaker. 8 Ohm operation, included indexing u-bracket and weather cover (White) - 911.1823.900
Biamp Desono EX-S10SUB-UB 10” Subwoofer Surface Mount Indoor/Outdoor Loudspeaker. 8 Ohm operation, included indexing u-bracket and weather cover (White) - 911.1823.900 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Biamp Desono EX-S10SUB-UB 10” Subwoofer Surface Mount Indoor/Outdoo...
Product Overview
The Biamp Desono EX-S10SUB is a 10-inch surface mount indoor/outdoor subwoofer that adds deep bass to EX-S6 or EX-S8 systems for full-range, foreground music playback. Its discreet matching enclosure blends into the background of an application. This makes it a strong fit as a surface mount subwoofer, an indoor/outdoor bass extension loudspeaker, and a companion subwoofer for distributed EX Series systems. This model ships with the indexing ClickMount U-Bracket and weather cover in a White finish.
Product Description
The EX-S10SUB provides additional deep bass to EX-S6 or EX-S8 systems, enabling full-range foreground music playback with a discreet enclosure that is easy to hear but difficult to spot. It operates as a passive, low-impedance subwoofer driven by a 10-inch treated paper cone. Designed for fast installation, Biamp's patented ClickMount brackets provide two mounting options: the pan-tilt bracket gives indexed aiming and allows vertical or horizontal mounting without moving the bracket, while the U-Bracket suits low-profile or exterior use and includes the ClickPlug with an integrated gland nut for weather-resistant installs. Both brackets are theft and tamper resistant. The subwoofer is ETL listed to comply with UL 1480A and CSA 62368-1, CE marked, RoHS compliant, and carries an IP54 environmental rating.
Key Features
- Low Frequency Extension — The subwoofer adds deep bass to EX-S6 and EX-S8 systems for full-range playback.
- Discreet Enclosure — The matching enclosure blends into an application while staying easy to hear.
- ClickMount Brackets — Patented pan-tilt and U-Bracket options speed installation.
- Indoor/Outdoor Rated — An IP54 rating supports indoor and outdoor installation.
- Tamper Resistant — Both mounting brackets are theft and tamper resistant.
- Certified Compliance — ETL listed to UL 1480A and CSA 62368-1, CE marked, and RoHS compliant.
Typical Applications
- Commercial Meeting Space — Adds low frequency extension to distributed EX Series systems.
- Multi-Purpose Room — Supports full-range foreground music playback.
- House of Worship — Indoor/outdoor rating supports interior and exterior bass coverage.
Technical Specifications
| Operating Mode | Passive, low impedance |
| Operating Environment | Indoor/Outdoor |
| Operating Range (-10dB) | 38 Hz to 140 Hz |
| Transducer | LF 1 x 10-inch treated paper cone |
| Sensitivity @ 1m | 89 dB (2.83 V); 89 dB (1 W, 8 ohm) |
| Power Handling | 300 W, 8 ohm |
| Required Processing | 35 Hz, 18 dB high-pass filter; DSP preset |
| Input Connection | Lever-actuated 4-position terminal block with pass-through |
| Compliance | ETL to UL 1480A, CSA C22.2#62368-1 |
| Environmental Rating | IP54 per IEC 60529 |
| Dimensions | 529 x 310 x 312 mm (20.8 x 12.2 x 12.3 in) |
| Weight (loudspeaker only) | 12.8 kg (28.26 lbs) |
| Finish | White |
| Mounting | indexing ClickMount U-Bracket and weather cover |
Frequently Asked Questions
What systems does the EX-S10SUB extend?
It adds deep bass to EX-S6 or EX-S8 systems for full-range foreground music playback.
Can the subwoofer be installed outdoors?
Yes. It carries an IP54 environmental rating for indoor and outdoor use.
What processing does it require?
A 35 Hz, 18 dB high-pass filter and DSP preset are required.
What mounting does this model include?
This model ships with the indexing ClickMount U-Bracket and weather cover.
