The Desono EX-S10SUB, 10 inch subwoofer provides additional deep base to the EX-S6 or EX-S8 systems for full-range, foreground music playback. With its discreet matching enclosure, EX-S10SUB easily blends in the background of an application, making it easy to hear, but difficult to spot.
Designed for easy and fast installation, our innovative, patented ClickMount™ brackets provide installers with two distinct mounting options. The ClickMount pan-tilt bracket provides indexed aiming control and allows for mounting EX Series quickly in either vertical or horizontal orientation without moving the bracket position. The ClickMount U-Bracket is also available for low profile mounting or exterior use and includes the ClickPlug with an integrated gland nut for weather-resistant applications. Both brackets are theft and tamper resistant.
- Exceptional audio clarity with discreet styling
- Easy to install with two mounting options
- Low frequency boost for distributed applications
- ETL listed to comply with UL 1480A, CSA 62368-1, CE marked, and RoHS compliant
|Operating Mode||Passive, low impedance|
|Operating Range (-10dB)||38 Hz to 140 Hz|
|Nominal Beamwidth (H x V)||Omnidirectional|
|Transducers||LF 1 x 10" (250 mm) treated paper cone|
|Sensitivity @ 1 m||89 dB (2.83 V)
89 dB (1 W, 8 Ω nominal impedance)
|Nominal Continuous Power Handling||49 V (300 W, 8 Ω)|
|Nominal Maximum SPL (Processed) @ 1 m||UXO 80 Hz: Continuous 112 dB Peak 118 dB
UXO 125 Hz: Continuous 113 dB Peak 119 dB
|Rated Continuous Voltage||39.8 V (32 dBV)|
|Rated Maximum SPL (Processed) @ 1 m||UXO 80 Hz: Continuous 110 dB Peak 122 dB
UXO 125 Hz: Continuous 111 dB Peak 123 dB
|Required Processing||35 Hz, 18 dB high-pass filter; DSP preset|
|Recommended Amplifiers||300 W - 600 W, 8 Ω (49 V - 69 V)|
|Input Connection||Lever-actuated wire clamping 4-position terminal block with pass-through|
|Mounting Provisions||ClickMount pan-tilt bracket or ClickMount U-Bracket|
|Compliance||ETL listed to comply with UL 1480A, CSA STD C22.2# 62368-1|
|Environmental Rating||IP54 per IEC 60529, IEC 60068-2-5 (Solar Radiation)
IEC 60068-2-11 (Salt Mist), IEC 60068-2-42 (SO2)
IEC 60068-2-60 (Chlorine)
|Dimensions H x W x D||529 mm x 310 mm x 312 mm [20.8" x 12.2" x 12.3"]|
|Weight (loudspeaker only)||12.8 kg [28.26 lbs]|
|Finish||High-impact UL94 5VB rated polycarbonate/ABS blend, painted UV resistant matte finish
Bracket: Heavily reinforced glass-filled nylon with UV-resistant painted matte finish cover
Color: Black (RAL 9017) or White (RAL 9016)
|Grille||Powder-coated perforated Marine Grade aluminum backed with hydrophobic cloth
Black or White
|Models (Order by mounting option)||EX-S10SUB-CM [-B,-W] - loudspeaker with large ClickMount pan-tilt bracket
EX-S10SUB-UB [-B,-W] - loudspeaker with ClickMount U-Bracket and ClickPlug
|Options||CMX-LG [-B,-W] - Large ClickMount Pan-tilt Bracket Kit
EXUB-S10 [-B,-W] - EX-S10 ClickMount U-Bracket kit
