Product Overview
The Biamp Community IV6-118S is a high power 18-inch direct-radiating installation subwoofer, finished in Black. Designed to complement IV6-1122 full-range array elements, it adds deep, impactful low-frequency support with 800W continuous power handling into 8 ohms. It suits houses of worship, auditoriums and multi-purpose venues that need compact sub-bass reinforcement. Its efficient design lets it share the same amplifier size as the IV6-1122 array elements.
Product Description
The IV6-118S is a compact, direct-radiating subwoofer engineered to integrate with IV6 array elements in any configuration. Large, balanced ports provide optimal enclosure tuning and even air-pressure distribution to the driver cone, reducing distortion and extending system longevity. A FEA-optimized ferrite motor with long linear excursion delivers deep bass response for the enclosure size. With 800W @ 8 ohms continuous power handling, it can be driven by the same size power amplifier as the IV6-1122 full-range elements, simplifying system design. The matched-size enclosure and aligned suspension point support seamless flown-array integration.
Key Features
- Long-excursion ferrite LF driver — FEA-optimized ferrite motor with symmetric movement suspension for deep, controlled bass.
- Array integration — Matched-size enclosure and aligned suspension point for seamless flown-array integration.
- 800W power handling — Handles 800W continuous (3200W peak) into 8 ohms.
- High sensitivity — High-sensitivity design minimizes power compression losses and required amplifier size.
Typical Applications
- House of worship
- Auditorium
- Multi-purpose room
- Commercial meeting space
Technical Specifications
| Type | 18-inch direct-radiating passive subwoofer |
| Transducer | 1 x 18" (457 mm) double-treated cone with 4" (102 mm) inner/outer wound voice coil, ferrite |
| Operating Range | 37 Hz to 132 Hz |
| Continuous Power Handling | 80V, 800W @ 8 ohms (3200W peak) |
| Sensitivity (1W/1m) | 102 dB |
| Finish | Black low gloss, textured painted 15 mm Baltic Birch plywood with powder-coated steel grille |
| Dimensions (H x W x D) | 20.00" x 28.12" x 28.08" (508 x 714 x 713 mm) |
Frequently Asked Questions
What is the IV6-118S designed to pair with?
It is designed to complement IV6-1122 full-range array elements and can be driven by the same size power amplifier, simplifying system design.
How much power does it handle?
It handles 800W continuous into 8 ohms with a 3200W peak rating.
Is it a passive subwoofer?
Yes. It is a passive, direct-radiating subwoofer requiring external amplification.
