Biamp Community IV6-1122WR05 12-inch two-way, 120 x 05 (Weather-Resistant, Grey) - 911.1192.900
Biamp Community IV6-1122WR05 12-inch two-way, 120 x 05 (Weather-Resistant, Grey) - 911.1192.900 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Biamp Community IV6-1122WR05 12-inch two-way, 120 x 05 (Weather-Res...
Product Overview
The Community IV6-1122WR is a weather-resistant 12-inch two-way modular vertical array element with 120 x 5 coverage for scalable sound reinforcement indoors or out. It supports long-throw line arrays, progressive-curvature arrays, and compact constant-curvature arrays. PolyGlas construction is built for a lifetime of outdoor performance.
Product Description
Aesthetically designed for installed applications, the IV6 is a scalable, adaptive sound reinforcement system. Cabinets can be combined into arrays of up to twenty elements at a 10:1 safety ratio and used with or without splay to deliver an extensive range of vertical coverage angles and throw distances. Built-in Passive Acoustic Optimization settings allow array response shaping using one amplifier channel, with up to 15 dB of element attenuation in 1.5 dB steps. The weather-resistant version uses PolyGlas outdoor cabinet construction, stainless steel hardware, and a marine-grade aluminum grille with hydrophobic fabric treatment, and exclusive Acoustic Optimization and Rigging SafetyCheck modules in EASE Focus 3 streamline array design.
Key Features
- Modular array element — Cabinets combine into arrays of up to twenty elements at a 10:1 safety ratio for scalable coverage.
- Versatile configurations — The element supports both constant-curvature and line-array applications with or without splay.
- Passive Acoustic Optimization — Built-in settings allow array response shaping using a single amplifier channel, with up to 15 dB of element attenuation.
- EASE Focus 3 support — Acoustic Optimization and Rigging SafetyCheck modules are integrated into EASE Focus 3 for predictable design.
- Weather-resistant — PolyGlas cabinet, stainless hardware, and marine-grade aluminum grille with hydrophobic fabric withstand outdoor exposure.
Typical Applications
- House of worship
- Auditorium
- Multi-purpose room
- Government space
- Commercial meeting space
Technical Specifications
| Configuration | 12-inch two-way modular vertical array element |
| Transducers | LF 1 x 12" ferrite, 3" VC; HF 2 x 1" exit, ketone polymer, neodymium |
| Operating range | 40 Hz to 18.5 kHz |
| Power handling | 400W @ 16 ohms (80V) |
| Max continuous output (4 cabinets) | 139 dB |
| Nominal beamwidth (H x V) | 120 x 5 (max) |
| Finish | Outdoor PolyGlas, Grey/Black/White, marine-grade aluminum grille |
| Dimensions (H x W x D) | 14.02" x 28.12" x 16.55" (356 x 714 x 421 mm) |
| Warranty | Biamp 5-year warranty |
Frequently Asked Questions
What applications is the IV6-1122WR (Grey) designed for?
It suits commercial install-sound venues such as houses of worship, auditoriums, and multi-purpose rooms.
How is it mounted?
It mounts using the model's rigging or bracket provisions and should be installed by a qualified AV integrator following Biamp guidance.
What power handling does it have?
Power handling is 400W @ 16 ohms (80V).
Does it require external processing?
For best performance, use the Community-provided loudspeaker presets and an appropriate DSP or amplified loudspeaker controller.
What is the warranty?
It is covered by the Biamp 5-year warranty.
