Biamp 910-01566 CMBB
Biamp 910-01566 CMBB is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Biamp 910-01566 CMBB
Product Overview
The Biamp CMBB is an on-wall back box for the Biamp CM ceiling loudspeaker range, built for commercial AV installations that need a flush-mount enclosure in a concrete or brick wall. It supports rack-mount-free ceiling speaker installation by giving in-ceiling and in-wall speaker models a dedicated backing enclosure. The CMBB is a companion accessory for the Biamp CM6T, CM6E, CM20T, and CM20DT loudspeakers.
Product Description
The CMBB is designed with a conical shape that lets it fit and stick securely into a concrete or brick wall opening, and it can also be used as a simple on-wall back box for surface applications. Installation is straightforward: the base plate mounts to the wall or ceiling first, then the back box fits onto the base plate by turning the ring counter-clockwise, after which the ring is secured with the three included screws. Once the back box is in place, the loudspeaker mounts directly into it. Integrators specifying the Biamp CM6T, CM6E, CM20T, or CM20DT for a commercial paging or background music system can use the CMBB to provide a clean, code-compliant back enclosure without a costly custom build-out. Browse the full Biamp collection for compatible ceiling speakers and accessories.
Key Features
- Conical Wall-Fit Design — The conical shape lets the back box fit and stick securely into a concrete or brick wall opening.
- Dual Mounting Use — The CMBB can be recessed into a wall or used as a simple on-wall back box for surface applications.
- Tool-Free Assembly — The back box attaches to its base plate by turning the ring counter-clockwise, then locks in place with three included screws.
- Compact Plastic Enclosure — The lightweight plastic housing keeps the assembly easy to handle and install on site.
Technical Specifications
| Model / SKU | CMBB / 910-01566 |
| Type | On-wall back box for CM- and CM-Design loudspeaker range |
| Compatible loudspeakers | CM6T, CM6E, CM20T, CM20DT |
| Outside diameter | 230 mm |
| Depth | 80 mm |
| Material | Plastic |
| Net weight | 0.70 kg |
Specifications sourced from the Biamp CMBB data sheet (Feb 2021). Confirm detailed specifications against current Biamp documentation.
