Barco UST Lens Support for F-Series Projectors - R9801956

Product Overview

The Barco UST Lens Support for F-Series Projectors (R9801956) is a mechanical support bracket for ultra-short-throw (UST) lenses fitted to Barco F-series projectors. Large UST lenses are heavy and place significant load on the projector lens holder, and this support takes up that weight. It is designed for rental and fixed-install setups where a UST lens is mounted for extended periods. The support helps keep the lens correctly positioned and protects the lens mount.

Product Description

Ultra-short-throw lenses extend well forward of the projector body and carry considerable mass. As shown in the product image, this support cradles the front of the UST lens and transfers its weight away from the projector lens holder. That reduces mechanical stress on the mount and helps maintain image stability and alignment over time. The support is intended for the Barco F-series projectors when configured with a UST lens. It is a recommended accessory whenever a heavy UST lens is installed, particularly for permanent installs or repeated rental deployments. Combine it with the matching lens adaptors and the rest of the Barco projection lineup for a complete F-series optical setup.

Key Features

• UST lens weight support — Takes up the weight of a heavy ultra-short-throw lens.
• Lens mount protection — Reduces mechanical stress on the projector lens holder.
• Alignment stability — Helps keep the lens positioned correctly for stable image geometry.
• F-series fit — Designed for Barco F-series projectors fitted with a UST lens.
• Install and rental use — Suited to permanent installs and repeated rental deployments.

Typical Applications

• Fixed installation — Permanent UST projection setups where the lens stays mounted long term.
• Large-venue rental — Supporting heavy UST lenses on F-series projectors at events.
• Touring — Protecting the lens mount during repeated transport and setup.

Technical Specifications

Frequently Asked Questions

What does the UST lens support do? It carries the weight of a heavy ultra-short-throw lens so the load does not rest entirely on the projector lens holder.

Which projectors does R9801956 fit? Barco F-series projectors configured with a UST lens.

When should I use it? Whenever a heavy UST lens is mounted, especially for permanent installs or repeated rental use.

Why is it important? It reduces stress on the lens mount and helps maintain stable lens position and image alignment.
