Barco DisplayPort 1.2 Quad Output Card for Select Barco Processors - R9004765B

Product Overview

The Barco DisplayPort 1.2 Quad Output Card (R9004765B) adds four DisplayPort 1.2 connectors to compatible Event Master processors for high-resolution output. The card supports two outputs at UHD 4K 60p, four outputs at 1200p 60 fps, or four outputs at UHD 4K 30 fps, giving operators flexible output configurations. It is HDCP 1.3 compliant and handles SMPTE, VESA, CEA, and custom resolutions. The card installs in the I/O slots of Barco's E2 and S3 family processors.

Product Description

The DisplayPort 1.2 Quad Output Card R9004765B provides four DisplayPort connectors that drive displays, projectors, and downstream devices from a Barco Event Master processor. Depending on the resolution required, the card delivers two DisplayPort outputs at UHD 4K 60p, four outputs at 1200p 60 fps, or four outputs at UHD 4K 30 fps. Support for SMPTE, VESA, CEA, and custom timings makes it suitable for mixed display environments, and HDCP 1.3 compliance covers protected content paths.

This card is an accessory for Barco's E2, E2 Generation 2, E2 Jr, E2 Tri-Combo, Ex, Ex Tri-Combo, S3 Standalone, S3 Tri-Combo, S3-4K, and S3-4K Jr processors. It pairs with the matching DisplayPort 1.2 Quad Input Card (R9004793B) and the HDMI 2.0 Quad Output Card (R9004792B). Browse the full Barco collection for processors and I/O cards.

Key Features

• 4x DisplayPort 1.2 Connectors — Four DisplayPort outputs in a single Event Master card slot.
• UHD 4K 60p Output — Supports two outputs at UHD 4K 60p for high-resolution destinations.
• Flexible Output Modes — Four outputs at 1200p 60 fps or four at UHD 4K 30 fps as alternatives.
• HDCP 1.3 Compliant — Supports protected content paths to compliant displays.
• Broad Resolution Support — Handles SMPTE, VESA, CEA, and custom resolutions.
• Wide Processor Compatibility — Works across the E2, Ex, and S3 Event Master families.

Typical Applications

• Live events and rental staging built on Barco Event Master processors
• Large-format display and projection output for general sessions
• Broadcast and control room video walls requiring DisplayPort output
• Mixed-resolution productions needing SMPTE, VESA, and custom timings

Technical Specifications

Frequently Asked Questions

Which processors accept the R9004765B? Barco's E2, E2 Generation 2, E2 Jr, E2 Tri-Combo, Ex, Ex Tri-Combo, S3 Standalone, S3 Tri-Combo, S3-4K, and S3-4K Jr processors.

How many outputs does it provide? Four DisplayPort 1.2 connectors, configurable as two UHD 4K 60p outputs, four 1200p 60 fps outputs, or four UHD 4K 30 fps outputs.

Is it HDCP compliant? Yes, the card is HDCP 1.3 compliant.

What resolutions are supported? SMPTE, VESA, CEA, and custom resolutions.

Is there a matching input card? Yes, the DisplayPort 1.2 Quad Input Card (R9004793B).
