Barco 100m Expansion link fiber TX/RX Module - R9004752

Product Overview

A fiber cable cannot move Event Master video on its own; the optical modules at each end convert the electrical expansion-link signal to light and back. The Barco 100m Expansion Link Fiber TX/RX Module, article number R9004752, is the transceiver pair (two per kit) required to run Barco 100-meter expansion-link fiber cables between an Event Master processor and a remote display. It serves Barco Event Master systems such as the E2, S3, and EC-210 for long-distance signal transport. This module is also the transceiver kit called out as a requirement by the rugged 100m fiber reel.

Product Description

This module kit contains two transceivers and is the required optical interface for Barco 100m expansion-link fiber cables. One module sits at the processor end and the other at the screen-side electronics, converting between the expansion-link electrical signal and the optical signal carried over the 100m fiber run. It is the part to order when building or repairing a link from individual components, and it is the specified module (R9004752) for the rugged 100m fiber on reel.

Pair these modules with a 100m fiber cable such as the Expansion Link Fiber Cable 100m or the Rugged Expansion Link Fiber 100m on Reel, and use the 4-Port Rack Mount MTP to opticalCON Adapters for panel integration. Browse the full range of Barco fiber transport gear in the Barco collection.

Key Features

• 100m transceiver pair — Two modules per kit terminate the optical link at both ends.
• Required for 100m cables — The mandatory optical interface for Barco 100-meter expansion-link fiber.
• Expansion-link conversion — Converts the Event Master electrical signal to light and back.
• Specified for the rugged reel — This is the R9004752 module called out for the rugged 100m fiber on reel.
• Component-level build — The right part for assembling or repairing a link from individual pieces.
• Event Master compatibility — Designed for Barco E2, S3, and EC-210 processing platforms.

Typical Applications

• Large-event and rental staging — Completing a 100m fiber link in a touring inventory.
• Fixed install with long cable runs — Terminating permanent 100m fiber paths.
• Arena and stadium video — Driving displays positioned away from the control area.
• Broadcast and multi-camera productions — Optical termination for high-bandwidth video transport.

Technical Specifications

Frequently Asked Questions

What does this module do? It converts the Event Master expansion-link electrical signal to and from light so video can travel over fiber; two modules terminate the link at each end.

Is this a cable? No. It is the transceiver pair (2 per kit) required to operate Barco 100m expansion-link fiber cables, which are sold separately.

Does it work with the rugged 100m reel? Yes. R9004752 is the specified TX/RX module kit for the Barco rugged 100m expansion-link fiber on reel.

Which Barco systems work with it? The Barco Event Master ecosystem, including the E2, S3, and EC-210 processors.
