AVPro Edge Weatherproof HDBaseT (CAT6) RECEIVER ONLY. ICT 18G, 70m 4K (100m HD) Slim Extender with I-Pass, Bi-Directional Power, RS232, IR - ICT for full HDR/HDMI Pass-Through. Full HDR, 4K60 4:4:4.

Product Overview

The AVPro Edge AC-EX70-444-RNE-W is a weatherproof HDBaseT receiver engineered for professional AV installations that require 4K video distribution in outdoor or environmentally demanding environments. Operating over a single CAT6 cable, it supports ICT 18Gbps signaling for full 4K60 4:4:4 and HDR pass-through up to 70 meters, and standard HD up to 100 meters. Designed for outdoor digital signage, covered stadium concourses, and hardened AV deployments, this slim receiver includes I-Pass, bidirectional power, RS232, and IR control in a weatherproof housing. It is sold as a receiver-only unit and is intended for pairing with a compatible AVPro Edge HDBaseT transmitter already present in the installation.

Product Description

The AC-EX70-444-RNE-W delivers high-bandwidth HDMI signals via HDBaseT over a single CAT6 cable to display endpoints in locations where standard indoor equipment cannot be used. Its weatherproof enclosure protects internal components against moisture, dust, and temperature variation, making it appropriate for partially exposed or fully outdoor display installations. ICT (Input Content Type) 18Gbps support ensures the receiver passes full HDR metadata—including HDR10 and Dolby Vision where supported by the source and display—without degradation.

Bidirectional power support allows the receiver to be powered from the transmitter end via the HDBaseT link, simplifying installations where running an additional power connection to the display location is impractical. The integrated RS232 and IR control pass-through enables display control commands from the head-end without additional control cabling, reducing infrastructure cost and installation complexity at the remote display location.

Key Features

• Weatherproof enclosure — Protects internal electronics against moisture, dust, and temperature extremes, enabling deployment in outdoor or semi-exposed AV locations.
• ICT 18Gbps HDBaseT — Input Content Type signaling at 18Gbps preserves full HDR metadata and 4K60 4:4:4 color fidelity from source to display.
• 70-meter 4K range, 100-meter HD range — Extends 4K HDR video 70 meters and HD video 100 meters over a single CAT6 cable without active repeaters.
• I-Pass (HDMI pass-through loop) — Provides a local HDMI output at the receiver for a secondary display or monitoring connection at the remote end.
• Bidirectional power via HDBaseT — The receiver can be powered from the transmitter end over the Cat cable, eliminating the need for a local power outlet at the display location.
• RS232 control pass-through — Passes serial control commands from the head-end to the display without additional RS232 cabling runs.
• IR control pass-through — Enables infrared remote control of the display from the source location over the HDBaseT link.
• Full HDR support — Passes HDR10 and compatible HDR formats with full metadata integrity for accurate display tone mapping.
• Slim form factor — Compact receiver profile simplifies mounting behind displays or within tight enclosures at the remote end.
• Receiver-only format — Purchase a single receiver to expand an existing HDBaseT system or replace a failed unit without purchasing a complete kit.

Typical Applications

• Outdoor digital signage — Drive weatherproof displays at building exteriors, transportation hubs, and sports venues with full 4K HDR content over a single buried or conduit-run CAT6 cable.
• Stadium and arena concourse displays — Distribute AV content to displays in partially exposed concourse areas where humidity and temperature cycling would damage standard indoor receivers.
• Outdoor hospitality AV — Extend video to pool deck, patio, and covered terrace displays in hotels, resorts, and restaurants that require all-weather AV infrastructure.
• Hardened corporate campus signage — Deploy display endpoints in covered parking structures, loading docks, and building overhangs where condensation and temperature variation are a concern.
• Security and surveillance monitoring — Extend HDMI video feeds from surveillance recorders to weatherproof monitor enclosures at remote security stations.

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Is a transmitter included with this product?

No. The AC-EX70-444-RNE-W is a receiver-only unit. It is intended for use with a compatible AVPro Edge HDBaseT transmitter, either as a replacement unit or as part of a multi-display system where a single transmitter drives multiple receivers. Verify transmitter compatibility before purchase.

What cable type is required, and does the distance change with CAT5e?

CAT6 is specified and recommended for the full 70-meter 4K range. CAT5e may achieve reliable performance at shorter 4K distances but is not guaranteed to reach 70 meters at 4K60 4:4:4. For the 100-meter HD range, CAT5e is generally suitable in low-interference environments.

What does ICT mean and why does it matter?

ICT stands for Input Content Type, which is an HDBaseT 2.0 feature that allows the system to pass full HDMI 2.0 signal characteristics—including HDR metadata flags and 4K60 4:4:4 color—over the HDBaseT link at 18Gbps. Without ICT, HDBaseT links are limited to approximately 10Gbps, which constrains the color subsampling and HDR capability of the transmitted signal.

Can the receiver be powered from the transmitter end without a local power outlet?

Yes. The bidirectional power feature allows the transmitter to supply power to the receiver over the HDBaseT Cat cable, which is particularly useful for outdoor installations where running a separate power circuit to the display location is cost-prohibitive or structurally difficult.

What does I-Pass provide?

I-Pass provides a local HDMI output at the receiver unit in addition to the primary HDMI output to the display. This secondary output can be used for a local monitor, video recorder, or signal distribution to a second nearby display without adding another transmitter or Cat cable run.
