AVPro Edge HDBaseT 2x10 Distribution Amplifier

Product Overview

The AVPro Edge AC-DA210-HDBT is a professional HDBaseT 2x10 distribution amplifier designed for large-scale commercial AV installations requiring reliable 4K signal distribution across multiple zones. It accepts two HDMI inputs and distributes the signal to two HDMI outputs and eight HDBaseT outputs, for a total of ten output paths from two sources. Supporting 4K60 4:4:4 with ICT (Invisible Compression Technology), this unit maintains full signal integrity over HDBaseT cabling up to 70 meters. It is the right choice for integrators specifying a high-port-count HDBaseT 4K60 distribution amplifier for corporate campuses, hospitality, or education environments.

Product Description

The AC-DA210-HDBT gives system designers two independent HDMI source inputs, each distributable to the full output bank simultaneously. Two local HDMI loop outputs allow direct connection to nearby displays, while eight HDBaseT outputs drive compatible receivers such as the AC-EX70-UHD-R2 and AC-EX70-444-RNE at distances up to 70 meters over Category cable.

ICT compression allows 4K60 4:4:4 HDR video to traverse standard HDBaseT infrastructure without visible quality loss, making it practical for installations that cannot justify the cabling cost of fiber or 10G AV-over-IP. The unit is rack-mountable and integrates into control systems via standard IP or RS-232 commands. All outputs are active simultaneously — no routing or switching is required, simplifying both programming and day-to-day operation.

Key Features

• 2 HDMI Inputs, 10 Total Outputs — two HDMI sources drive two local HDMI outputs and eight HDBaseT outputs simultaneously.
• 4K60 4:4:4 with ICT — delivers full-resolution, full-color-depth 4K at 60 Hz over standard HDBaseT infrastructure using Invisible Compression Technology.
• 18Gbps Signal Bandwidth — supports the full HDMI 2.0 specification including HDR10 and Dolby Vision pass-through.
• 70-Meter HDBaseT Range — each HDBaseT output reaches displays up to 70 meters away over Cat6/6A cable.
• Compatible with AC-EX70-UHD-R2 and AC-EX70-444-RNE Receivers — works directly with AVPro Edge's 4K60 HDBaseT receiver lineup.
• Local HDMI Loop Outputs — two HDMI outputs allow connection to displays or devices co-located with the amplifier.
• Rack-Mountable Form Factor — standard 1U rack chassis fits into any AV equipment rack.
• IP and RS-232 Control — integrates into Crestron, Savant, Control4, and other control systems.

Typical Applications

• Corporate campus digital signage distribution to 10 or more display zones
• University lecture hall and classroom AV infrastructure
• Hospitality and hotel in-room entertainment systems requiring multi-zone 4K distribution
• Houses of worship with multiple screens across a large venue
• Broadcast and production facilities needing a reliable 4K60 HDBaseT distribution backbone
• Large retail environments with multiple display endpoints from a central AV rack

Technical Specifications

Competitor Comparison

The following table compares the AC-DA210-HDBT against two competing HDBaseT distribution amplifiers commonly specified in commercial AV projects.

Frequently Asked Questions

Can both HDMI inputs be distributed to all 10 outputs at the same time?

No — the AC-DA210-HDBT is a distribution amplifier, not a matrix switcher. Each input distributes to all outputs, but only one source can be selected at a time across all outputs. If you need to route different sources to different outputs independently, a matrix switcher is required.

Which cable type and category is recommended for the HDBaseT outputs?

AVPro Edge recommends shielded Cat6 or Cat6A cable for all HDBaseT runs. Unshielded Cat6 may work in low-interference environments but shielded cable reduces the risk of signal degradation in electrically noisy commercial installations.

Does ICT introduce visible compression artifacts?

ICT (Invisible Compression Technology) is designed to operate below the threshold of human perception. In standard viewing conditions at typical display sizes, ICT compression is not visible. It is not lossless, but the quality difference is not discernible in practice.

Is the AC-DA210-HDBT compatible with third-party HDBaseT receivers?

The unit is designed and tested with AVPro Edge receivers (AC-EX70-UHD-R2 and AC-EX70-444-RNE). Compatibility with third-party HDBaseT receivers is not guaranteed, particularly for 4K60 4:4:4 with ICT, which requires a compatible ICT decoder at the receiver end.

Can this unit be controlled by a third-party control system?

Yes. The AC-DA210-HDBT supports IP (TCP/IP) and RS-232 control, making it compatible with Crestron, AMX, Control4, Savant, and other control systems. API documentation and drivers are available from AVPro Edge.
