AVPro Edge 10G SDVOE 4K HDMI AV-over-IP PoE Transceiver (Encoder/Decoder) with the ICRON USB

Product Overview

The AVPro Edge 10G SDVoE 4K HDMI AV-over-IP PoE Transceiver with ICRON USB (AC-MXNET-10G-TCVR-USBX) is a dual-mode encoder/decoder that distributes uncompressed 4K video over standard 10 Gigabit Ethernet infrastructure. Designed for the SDVoE ecosystem, it provides zero-perceptible-latency performance for applications where frame-accurate switching and pixel-perfect image quality are required — including corporate collaboration spaces, university campuses, and broadcast facilities. The integrated ICRON USB extension module allows USB 2.0 and 3.0 peripherals such as touchscreens, cameras, and keyboards to follow the signal path over the same network, eliminating the need for a separate USB extension system. Powered entirely by PoE, the transceiver simplifies installation by eliminating local power requirements at each endpoint.

Product Description

This transceiver operates as either an encoder (source side) or decoder (display side) within a SDVoE-based AV-over-IP network, determined by configuration — no hardware swap required. It delivers uncompressed 4K UHD 60Hz video at less than one millisecond of latency over 10G Ethernet, maintaining full color fidelity and HDR metadata through the network. The ICRON USB module integrated into this variant extends USB 2.0 and USB 3.0 devices — including interactive whiteboards, PTZ cameras, and HID peripherals — across the same 10G network switch fabric used for video. PoE (Power over Ethernet) powers the unit directly from the switch, meaning no local power adapter or outlet is needed at the display or source location. The SDVoE architecture supports many-to-many routing, multicast distribution, and video wall configurations managed through a central SDVoE controller. HDCP 2.2 is supported for protected content distribution.

Key Features

• Encoder/Decoder in One Unit — configure as encoder or decoder in software; the same hardware serves both roles, reducing spares inventory.
• Uncompressed 4K UHD 60Hz — full-resolution, full-frame-rate video with no compression artifacts over 10G Ethernet.
• Sub-1ms Latency — SDVoE technology delivers near-zero latency suitable for live switching, interactive applications, and real-time monitoring.
• ICRON USB Extension — extends USB 2.0 and USB 3.0 devices (touchscreens, cameras, keyboards, PTZ controllers) over the network alongside video.
• Power over Ethernet (PoE) — the unit is powered by the network switch, eliminating local power adapters at each endpoint location.
• SDVoE Ecosystem Compatible — integrates with SDVoE-certified switches, controllers, and endpoints for managed many-to-many routing and video walls.
• HDCP 2.2 Support — handles protected content across the AV-over-IP network.
• Flexible Mounting — rack, wall, or desktop deployment to suit the installation environment.

Typical Applications

• University and corporate campus AV-over-IP distribution replacing point-to-point HDMI runs with scalable 10G network infrastructure
• Collaborative meeting spaces requiring USB peripheral sharing (cameras, interactive displays) alongside video distribution
• Broadcast and production environments needing frame-accurate, sub-millisecond latency switching between sources
• Digital signage networks distributing 4K content to multiple displays from a central server over existing 10G Ethernet
• Control rooms requiring simultaneous multi-source monitoring with low-latency video feeds

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Does this unit function as both encoder and decoder, or do I need separate units?

The same hardware unit functions as either encoder or decoder, configured in software. This means you can stock a single SKU and configure units as needed during installation, reducing spare parts complexity.

What switch hardware is required for a SDVoE network?

SDVoE requires a 10 Gigabit Ethernet switch with IGMP snooping and multicast support. Specific certified switch models are available through AVPro Edge and the SDVoE Alliance. Standard enterprise 10G switches from major brands typically work when configured correctly.

What USB devices does the ICRON module support?

The ICRON module supports USB 2.0 and USB 3.0 devices including interactive whiteboards, touchscreen displays, PTZ cameras, keyboards, mice, and most HID-class peripherals. Devices with high real-time bandwidth requirements (e.g., USB audio interfaces) should be tested for compatibility.

How is this unit powered?

The transceiver is powered entirely by Power over Ethernet (PoE) from a compatible 10G PoE switch. No local power supply is needed at the endpoint, which simplifies conduit and outlet requirements during installation.

What is the maximum distance this unit can transmit?

Over 10G fiber (using SFP+ optics), distances of hundreds of meters to kilometers are achievable depending on the fiber type and optic modules used. Over copper SFP+ DAC cables, distances are typically up to 10 meters between switch and endpoint.
