Avocor AVW-5555 – 55" 4K All-in-One Interactive Display

The Avocor AVW-5555 is a 55-inch 4K all-in-one interactive touchscreen display with an integrated wide-angle camera, far-field microphone array, and forward-facing speakers — a single device that turns a huddle room or focus room into a complete video collaboration space.

Product Overview

The AVW-5555 W Series is a 55-inch 4K interactive touchscreen display for huddle rooms, small conference rooms, and executive offices. Unlike a standard touch display that requires a separate camera, microphone, and speaker kit, the AVW-5555 builds conference-grade AV directly into the chassis: an integrated extra-wide-angle 1080p camera, four far-field beam-forming microphones, and four 10W forward-facing speakers. For organizations standardizing small meeting room video conferencing on Microsoft Teams, Zoom, or RingCentral, this all-in-one collaboration display cuts hardware count, cabling, and installation time to a fraction of a component-based room build.

Product Description

The display uses InGlass Intelligent Touch with 3mm optically bonded, anti-glare glass for zero-parallax, ultra-fast inking — up to 20 touch points with support for four fine-tip styluses plus palm rejection, so whiteboarding feels natural. A single USB-C cable (60W power delivery) connects a laptop and carries 4K video, audio, touch, and ethernet while charging the device, giving walk-up users a one-cable BYOD meeting start. For permanently installed room systems, the OPS slot accepts a Windows compute module or UC appliance, and dedicated HDMI and DisplayPort inputs each pair with a USB-B touch port so touch tracks the active source.

The AVW-5555 is also Microsoft Azure certified, with built-in IoT sensors — proximity, room temperature, and ambient brightness — that report to the Azure Digital Twins platform, giving facilities teams real occupancy and environmental data from every huddle space. With a 400 x 400mm VESA pattern and a net weight under 100 lbs, it installs on standard commercial display mounts. For larger interactive rooms, compare it against the bigger formats in the Avocor collection at Creation Networks.

Key Features

• All-in-One Conferencing Hardware — The integrated extra-wide-angle 1080p camera, four far-field beam-forming microphones, and four 10W forward-facing speakers eliminate separate room AV components.
• 20-Point InGlass Touch — InGlass Intelligent Touch on 3mm optically bonded glass delivers zero-parallax, ultra-fast inking with support for four fine-tip styluses and palm rejection.
• Single-Cable USB-C Meetings — One USB-C connection carries 4K video, audio, touch, ethernet, and 60W of laptop charging, so meetings start the moment a presenter plugs in.
• UC Platform Flexibility — The display is optimized for Microsoft Teams, Zoom, and RingCentral, working with whatever conferencing software your organization runs.
• Microsoft Azure Certified Sensors — Built-in proximity, temperature, and brightness sensors connect to Azure Digital Twins for room usage analytics and environmental monitoring.
• OPS Slot for Room Compute — An internal OPS slot houses a Windows PC or UC appliance for a clean, appliance-style room system with no external boxes.
• 4K Commercial Panel — 3840 x 2160 resolution at 60Hz with 500 cd/m² brightness and 178-degree viewing angles keeps content sharp across the room.
• Integrator-Friendly Control — RS-232, IR input, and LAN in/out ports support control systems and network passthrough in commercial deployments.

Typical Applications

• Huddle room — complete video collaboration room from a single wall-mounted device
• Conference room — small meeting rooms standardizing on Teams, Zoom, or RingCentral
• Commercial meeting space — focus rooms and drop-in collaboration spaces with BYOD USB-C connection
• Training room — interactive whiteboarding with stylus support for small-group sessions

Technical Specifications

Frequently Asked Questions

Which video conferencing platforms work with the AVW-5555?

The integrated camera, microphone array, and speakers are optimized for UC platforms including Microsoft Teams, Zoom, and RingCentral. Connect a laptop over USB-C or install a Windows compute module in the OPS slot to run your platform of choice.

Do I still need a separate camera and microphone for a huddle room?

No. The AVW-5555 includes an extra-wide-angle 1080p conference camera, four far-field beam-forming microphones, and four 10W speakers — a complete small-room AV system in one display.

How does the single-cable USB-C connection work?

The USB-C input intelligently connects a laptop to the display, delivering 4K video, audio, USB touch, and ethernet while supplying up to 60W of charging power. When the laptop is unplugged, its content leaves the screen with it.

What touch operating systems are supported?

The 20-point InGlass touch system supports Windows 8 and 10, with Mac OSX and Linux supporting single touch. Touch connects over USB-B or the USB-C cable.

How is it installed?

The display uses a standard 400 x 400mm VESA pattern and weighs 45.3kg (99.87 lbs) net, so it mounts on common commercial wall mounts or mobile stands. Creation Networks offers professional installation and room design for multi-room rollouts.

What are the Azure IoT sensors for?

Built-in proximity, temperature, and brightness sensors report to the Microsoft Azure Digital Twins platform, giving IT and facilities teams real data on room occupancy and environment for space planning and automation.

Where can I compare other Avocor displays?

Browse the full Avocor collection at Creation Networks for larger interactive displays and ultra-wide conference room formats, or contact our team for configuration guidance and volume pricing.
