Avid NEXIS | F5 400TB, Half populated 4x 100TB Media Packs, includes; two SSDs, two 10TB spare drives, two 220V PSU, 5 cooling modules, rack mount kit. Elite Support

Product Overview

The Avid NEXIS | F5 400TB shared storage system is a scalable enterprise storage engine designed for mid-to-large broadcast facilities and post-production studios requiring high-performance shared storage with a clear growth path. Half-populated with four 100TB HDD Media Packs, this configuration delivers 400TB of usable capacity and up to 1.92 GB/s of aggregate bandwidth over 25/50GbE networking, with the chassis ready to accept four additional packs for a full 800TB configuration. This bundle includes Avid Elite Support—Avid's highest service tier.

Product Description

The Avid NEXIS | F5 400TB provides a scalable entry into F5 enterprise storage. Four 100TB HDD Media Packs deliver 400TB of usable capacity and 1.92 GB/s of aggregate bandwidth—sufficient for concurrent 4K and HDR editorial workflows across a substantial team. When additional capacity is required, four more 100TB Media Packs can be added to the same chassis to reach 800TB and 3.84 GB/s without chassis replacement.

The F5 Controller ships with two 40/50Gbps Ethernet QSFP28 interfaces (unpopulated) for 25GbE or 50GbE production network connectivity. The included Avid NEXIS | FS license provides centralized workspace management, per-user bandwidth allocation, and integration with Avid Media Composer, Pro Tools, Adobe Premiere Pro, Apple Final Cut Pro, and DaVinci Resolve. Dual 220V redundant power supplies and five cooling modules support continuous 24/7 operation. Two 10TB spare drives and two SSDs are included. The system ships with a rack-mount kit.

Note: Avid NEXIS | SDA or SDA+ is required for all F5 configurations and is sold separately. Drive slot covers are not required for F5 engine chassis. Elite Support provides 24/7 telephone access, priority hardware replacement, and top-priority technical escalation.

Key Features

• 400TB Expandable Capacity — Four 100TB HDD Media Packs provide 400TB of usable storage with in-chassis expansion to 800TB by adding four additional packs—no chassis replacement required.
• 1.92 GB/s Aggregate Bandwidth — Four Media Packs at 480 MB/s each support concurrent high-resolution workflows, scaling to 3.84 GB/s at full population.
• 25/50GbE QSFP28 Connectivity — Two 40/50Gbps QSFP28 Ethernet interfaces (unpopulated) for integration with 25GbE or 50GbE switching infrastructure.
• Avid NEXIS | FS License Included — Centralized file system management, per-user workspace allocation, and bandwidth control.
• Redundant 220V Power Supplies — Dual PSUs for uninterrupted 24/7 production operation.
• Two 10TB Spare Drives — Hot-spare HDDs for immediate response to Media Pack drive failures.
• Two SSDs Included — Solid-state drives for file system metadata and cache performance.
• Five Cooling Modules — Redundant cooling for continuous-duty rack-mount deployments.
• Rack-Mount Kit Included — Standard 19-inch mounting hardware included.
• Elite Support — 24/7 telephone access, priority hardware replacement, and highest-priority technical escalation.
• E-Series Compatible — Integrates with existing NEXIS E-Series infrastructure as a dedicated storage group.

Typical Applications

• Broadcast production facility shared storage with planned growth
• Post-production studio collaborative 4K/HDR editorial
• Government media operations
• Multi-purpose production environment with mixed NLE platforms
• Training and education production facility storage

Technical Specifications

Frequently Asked Questions

Q: Can I expand this system to 800TB?
A: Yes. The half-populated chassis supports four additional 100TB Media Packs for a full 800TB and 3.84 GB/s configuration without chassis replacement. Contact Creation Networks for Media Pack pricing and expansion guidance.

Q: Is Avid NEXIS | SDA or SDA+ required?
A: Yes. SDA/SDA+ is required for all F5 configurations and sold separately. Contact Creation Networks for SDA/SDA+ guidance.

Q: What network infrastructure is required?
A: A 25GbE or 50GbE switch is required for rated F5 bandwidth. Existing 10GbE infrastructure will limit achievable throughput.

Q: What is Elite Support?
A: Elite Support provides 24/7 telephone access, priority hardware replacement, and the highest-priority escalation for system issues. Recommended for 24/7 broadcast and production operations.
