AVer TR535N NDI Dual Lens Auto Tracking Camera

Product Overview

The AVer TR535N is a professional-grade NDI auto tracking PTZ camera designed for enterprise, higher education, government, and house of worship environments that require reliable, operator-free video capture. Featuring a 30X optical zoom 4K NDI camera with a dual-lens design, the TR535N delivers up to 4K at 60 fps across HDMI, USB, 3G-SDI, and IP outputs simultaneously. As an NDI High Bandwidth auto tracking camera, it supports ultra-low-latency video distribution over standard IP networks, making it a practical choice for AV integrators deploying in broadcast studios, lecture halls, and large meeting spaces. PoE++ support simplifies installation by delivering both power and data over a single CAT cable, reducing cabling complexity in ceiling and wall-mount deployments.

Product Description

The AVer TR535N 30X 4K NDI dual lens auto tracking camera is purpose-built for professional AV deployments where consistent, high-quality video must be produced without a dedicated camera operator. Its 1/2.8" CMOS sensor captures at 8 megapixels with up to 4K resolution at 60 fps, while 30X optical zoom and a 62.3° horizontal field of view at wide angle give operators the range needed to cover large rooms from a fixed mount position.

The dual-lens design is a defining feature: a tiltable secondary lens enables flexible installation in both wall-mount and ceiling-mount configurations, allowing AV designers to optimize camera placement for the space. Four AI-driven tracking modes — Presenter, Zone, Hybrid, and Segment — allow the camera to automatically follow a speaker, lock onto preset zones, or switch between modes based on scene conditions. The Shield Zone function can exclude defined areas from the tracking field to avoid distracting motion in high-traffic spaces.

For AV system integration, the TR535N supports RS-232, RS-422, VISCA, PELCO-D, CGI, and ONVIF control protocols, as well as VISCA over IP. It is compatible with leading control systems including Crestron, Extron, Q-SYS, and Barco, and carries Microsoft Teams and Zoom certifications. The camera is TAA and NDAA compliant, making it eligible for government and federal procurement. IP streaming supports RTSP, RTMP, SRT, HLS, and NDI High Bandwidth with up to 10 simultaneous streams. The camera ships with ceiling mount brackets, RS-232 cabling, and a remote control, and is backed by AVer's 5-year AVerCare warranty with Advanced Replacement.

Key Features

• 30X Optical Zoom with 4K60 Output — 1/2.8" CMOS sensor, 8MP, delivers 4K at 60 fps over HDMI, USB, IP, and 3G-SDI outputs simultaneously.
• NDI High Bandwidth Streaming — Native NDI High Bandwidth and NDI HX2 support enables ultra-low-latency IP video distribution without additional encoders.
• Dual-Lens Design with Flexible Mounting — Tiltable secondary lens allows wall-mount and ceiling-mount installation, adapting to varied room geometries without compromising image angle.
• Four AI Auto Tracking Modes — Presenter, Zone, Hybrid, and Segment tracking with Shield Zone exclusion provides reliable, hands-free operation across diverse venue types.
• PoE++ Power Delivery — Supports IEEE 802.3bt PoE++ to power the camera and deliver control over a single Ethernet cable, simplifying rack and ceiling infrastructure.
• Comprehensive AV Control Protocol Support — RS-232, RS-422, VISCA, PELCO-D, CGI, ONVIF, and VISCA over IP for integration with Crestron, Extron, Q-SYS, and other control systems.
• Wide Streaming Protocol Coverage — Supports RTSP, RTMP, SRT, HLS, NDI, and LLDP; H.264, H.265, and MJPEG compression; VBR/CBR bitrate control from 512 Kbps to 64 Mbps.
• Voice Tracking Capability — Compatible with select microphones and AVer PTZ Link software or MT300N tracking box for microphone-driven camera preset automation.
• TAA and NDAA Compliant — Meets Trade Agreements Act and National Defense Authorization Act requirements for government and federally funded deployments.
• 5-Year AVerCare Warranty — Industry-leading coverage with Advanced Replacement and 24-hour turnaround in year one; accessories covered for 1 year.
• Tally Light Indicator — Illuminated tally light signals active camera status for multi-camera live production workflows.
• Kensington Lock Support — Physical security slot for fixed installations in public or shared spaces.

Typical Applications

• Conference room and boardroom video capture with automatic presenter tracking
• Higher education lecture hall recording and live streaming
• House of worship broadcast and streaming production
• Government and federal agency video conferencing (TAA/NDAA compliant)
• Broadcast studio and multi-camera live production environments
• Training room and corporate all-hands room deployments
• Auditorium and multi-purpose room AV system integration
