AVer TR315 AI Auto Tracking PTZ Camera (NDI version)
Product Overview
The AVer TR315N is a professional-grade 4K PTZ camera engineered for facilities where signal transport, low-latency streaming, and hands-free operation are critical requirements. Built on a 1/2.8" 8MP CMOS sensor and delivering up to 4K60 via HDMI, 3G-SDI, USB, and NDI|HX3 simultaneously, this camera fits cleanly into IP-based AV infrastructures without compromising legacy SDI workflows. Three AI-driven tracking modes — Presenter, Zone, and Hybrid — eliminate the need for a dedicated camera operator across a wide range of installation environments. With PoE+ support, RS-232/RS-422 serial control, and VISCA/ONVIF compatibility, the TR315N integrates into virtually any control system or broadcast chain.
Product Description
The AVer TR315N v3 addresses the demands of integrators deploying cameras in houses of worship, university lecture halls, broadcast studios, and corporate training environments where both NDI|HX and traditional SDI outputs must coexist. The camera's NDI|HX3 implementation delivers 4K60 transport with latency under 100ms, making it suitable for live production workflows that rely on NewTek/Vizrt ecosystems, vMix, Telestream, and similar platforms. A 12x optical zoom with a horizontal field of view spanning 70° to 6° provides the coverage depth needed in mid-to-large rooms without mechanical repositioning between shots.
AI tracking operates in three configurable modes: Presenter Mode tracks full or half-body subjects with click-to-track initiation; Zone Mode establishes up to four content zones for display or whiteboard capture; Hybrid Mode switches automatically between presenter and zone tracking depending on subject position. When paired with compatible microphones from Shure, Sennheiser, Yamaha, ClearOne, Nureva, or Audio-Technica, the TR315N can perform voice-activated PTZ preset recall through AVer's PTZ Link software or an MT300N tracking box — eliminating the need for a dedicated room PC. The camera ships with ceiling mount brackets, RS-232 and DIN-8 to D-Sub9 cables, and an IR remote, simplifying first-time installations. A 5-year manufacturer warranty on the camera body underscores AVer's confidence in the platform.
| Feature | Detail |
|---|---|
| Sensor | 1/2.8" 8MP 4K CMOS |
| Max Resolution | 3840 x 2160 @ 60fps |
| Optical Zoom | 12x optical / 12x digital |
| NDI Version | NDI|HX3 (<100ms latency) |
| Video Outputs | HDMI, 3G-SDI, USB 3.0, NDI|HX3, IP |
| Control | RS-232, RS-422, VISCA, ONVIF, PoE+ |
| Pan / Tilt | ±170° pan / -30° to +90° tilt |
Key Features
- NDI|HX3 Transport — delivers 4K60 video over IP with latency under 100ms, compatible with NewTek, vMix, Telestream, and other NDI-enabled platforms.
- Simultaneous Multi-Output — outputs HDMI, 3G-SDI, USB, and IP/NDI concurrently, supporting mixed analog-digital infrastructures without a splitter or distribution amplifier.
- AI Auto-Tracking (3 Modes) — Presenter, Zone, and Hybrid modes provide flexible hands-free coverage for speakers, whiteboards, and content zones.
- 12x Optical Zoom — 70° to 6° horizontal field of view covers front-of-room to tele framing across mid-size to large venues.
- PoE+ Powered — single-cable installation over Gigabit Ethernet reduces conduit and AC outlet requirements at the camera location.
- RS-232/RS-422 Serial Control — integrates with Crestron, Extron, AMX, and other control systems via standard VISCA command sets.
- Voice Tracking Compatible — works with select Shure, Sennheiser, Yamaha, ClearOne, Nureva, and Audio-Technica microphone systems for audio-driven preset recall.
- Wide Dynamic Range (WDR) — balances exposure in mixed or high-contrast lighting without manual iris adjustment.
- Tally Light — built-in red tally indicator supports multi-camera live production workflows.
- 5-Year Warranty — manufacturer warranty on camera body provides long-term deployment confidence.
Typical Applications
- House of worship — unmanned 4K capture with speaker tracking across large sanctuaries and simultaneous NDI|HX streaming to broadcast or recording systems.
- Broadcast studio — 3G-SDI and NDI|HX3 dual-output supports traditional switcher integration and modern IP production simultaneously.
- Training room — Zone and Hybrid tracking modes capture both instructor movement and screen content without operator intervention.
- Auditorium — 12x optical zoom and ±170° pan range provide full-room coverage from a single ceiling or wall mount position.
- Conference room — PoE+ single-cable deployment and ONVIF/VISCA compatibility simplify integration with UC platforms and room control systems.
- Multi-purpose room — Hybrid tracking adapts automatically between presenter and content-zone modes as room usage changes.
Technical Specifications
| Specification | Value |
|---|---|
| Model / SKU | TR315N v3 / PTR315NV3 |
| Image Sensor | 1/2.8" 8MP 4K CMOS |
| Max Video Resolution | 3840 x 2160 (4K UHD) @ 60fps |
| Optical Zoom | 12x optical |
| Digital Zoom | 12x digital |
| Horizontal Field of View | 70° (wide) to 6° (tele) |
| Pan Range | ±170° |
| Tilt Range | -30° to +90° |
| Video Outputs | HDMI, 3G-SDI, USB 3.0, NDI|HX3, IP Streaming |
| NDI Version | NDI|HX3 (latency <100ms, 4K60) |
| Streaming Formats | H.264, H.265, MJPEG, AAC audio |
| Network Protocols | IPv4, TCP, UDP, HTTP, RTSP, RTMP, VISCA over IP, ONVIF |
| Serial Control | RS-232, RS-422 (VISCA) |
| Network Interface | Gigabit Ethernet (RJ-45) |
| Audio I/O | 3.5mm stereo analog input, embedded audio |
| Power | PoE+ (IEEE 802.3at) or DC 12V/5A adapter |
| AI Tracking Modes | Presenter, Zone, Hybrid |
| Compatible Software | Crestron, Extron, Panopto, Kaltura, vMix, Zoom, Telestream, NewTek/Vizrt |
| Security | Kensington security lock slot |
| Warranty | 5-year (camera), 1-year (accessories) |
Frequently Asked Questions
Q: What is the difference between the AVer TR315N and the TR315?
A: The TR315N includes NDI|HX3 support for IP-based video transport over standard Gigabit Ethernet, making it the preferred choice for installations using NDI-capable switchers, recording systems, or media servers. The TR315 (non-NDI) does not include NDI|HX but retains HDMI, 3G-SDI, USB, and IP streaming outputs. Both cameras share the same 4K60 sensor, 12x optical zoom, AI tracking modes, and physical form factor. Choose the TR315N when your infrastructure includes NewTek, vMix, Telestream, or other NDI-enabled production tools.
Q: Does the TR315N require a separate PC or server for AI tracking?
A: No. AI tracking (Presenter, Zone, and Hybrid modes) runs entirely on-device and does not require a connected PC. For voice-activated PTZ preset recall using compatible microphones, you can run AVer PTZ Link software on an existing room UC compute device, or use the AVer MT300N tracking box — which runs PTZ Link in a dedicated appliance without a separate PC or ongoing OS management.
Q: What NDI version does the TR315N support, and what latency can I expect?
A: The TR315N supports NDI|HX3 — the third generation of the NDI HX protocol — delivering 4K60 video over IP with latency under 100ms. NDI|HX3 offers improved compression efficiency over NDI|HX2, reducing bandwidth consumption while maintaining high image quality. The camera must be on the same network as receiving NDI devices; no additional NDI licensing is required beyond the camera itself.
Q: Can the TR315N be powered over Ethernet?
A: Yes. The TR315N supports PoE+ (IEEE 802.3at, up to 30W), allowing the camera to receive both power and network connectivity over a single Cat5e/Cat6 cable. A PoE+ capable switch or midspan injector is required at the network infrastructure level. An AC power adapter (DC 12V/5A) is also included for installations where PoE+ is not available.
Q: Which control systems and platforms are compatible with the TR315N?
A: The TR315N supports RS-232 and RS-422 serial control using VISCA command sets, and VISCA over IP for network-based PTZ control. It is ONVIF-compliant for integration with VMS platforms. Verified compatible control systems and software include Crestron, Extron, AMX, Echo360, Panopto, Kaltura, vMix, Zoom, Microsoft Teams, Cisco Webex, Telestream, and NewTek/Vizrt products. For a current integration guide, contact Creation Networks.
Q: What mounting options are included with the TR315N?
A: The camera ships with two ceiling mount brackets and a cable fixing plate, along with M2 and M3 mounting screws. A standard 1/4"-20 threaded socket on the camera body allows use with third-party camera mounts and poles. Wall and ceiling mount placements are both supported; the tilt range of -30° to +90° accommodates front-of-room positioning at most standard ceiling heights.
