AVer MD120UI Medical-Grade PTZ Camera with 20x Optical Zoom (White)

Product Overview

The AVer MD120UI medical-grade PTZ camera is purpose-built for 24-hour patient monitoring in clinical environments, combining 20x optical zoom and 4K resolution with AI-driven body and facial tracking, infrared night vision, and a certified anti-UV housing. Designed as the first PTZ camera specifically engineered for patient monitoring, it allows nursing staff to observe patients remotely with precision — capturing facial detail, eye movement, and body contour — without entering the room. A built-in omnidirectional microphone transmits real-time audio to nursing stations, and a hardware Privacy Mode halts all video and audio transmission on demand to maintain compliance with patient privacy regulations. At $2,639.99, the MD120UI includes a 3-year AVerCare warranty with 24-hour advance replacement.

Product Description

The AVer MD120UI medical-grade PTZ camera centers on a 1/2.8" Exmor CMOS sensor delivering 8MP resolution at up to 4K 60fps. The 20x optical zoom (f=4.5–90mm) covers a 62.3° wide-angle to 3.6° telephoto horizontal field of view, giving clinical staff the ability to zoom into specific anatomical areas of interest — face, eyes, wound sites — from a ceiling mount position without disturbing the patient.

AI algorithms continuously detect a patient's body contour and activate AI Facial/Eyes Tracking to monitor specific regions of interest automatically. The camera also runs fall detection: if a patient falls within the field of view, an alert is triggered to nursing station personnel, enabling faster response without requiring constant manual observation. Up to 256 preset positions are stored via RS-232 or IP control, allowing staff to recall clinically defined views instantly.

The infrared night vision mode enables monitoring in completely dark rooms, essential for overnight patient care without disturbing sleep. Anti-UV housing protects the camera from disinfection procedures using UV-C light, a critical requirement in clinical environments. The hardware Privacy Mode disables both video and audio transmission at the device level, ensuring no data leaves the room when activated — a privacy indicator light confirms the mode is active. Output options include HDMI, IP, and USB 3.1 Gen 1, with PoE+ for single-cable ceiling installation. Control is via VISCA over RS-232, RS-422, or IP.

Key Features

• 4K 60fps Resolution — 1/2.8" Exmor CMOS sensor captures 8MP video at up to 60fps in 4K, providing clinical-grade image quality for remote assessment of fine physiological detail.
• 20x Optical Zoom — f=4.5–90mm lens zooms from a 62.3° wide field to a 3.6° telephoto view, enabling observation of specific body areas from a fixed ceiling position.
• AI Facial and Eyes Tracking — Automatically detects patient body contour and focuses on face and eyes, reducing the manual workload for nursing staff monitoring multiple patients.
• AI Fall Detection Alert — Detects abnormal patient movement events within the camera's field of view and triggers an alert to nursing station personnel for rapid response.
• Infrared Night Vision — Auto-activating IR mode enables 24/7 patient monitoring in complete darkness without disturbing patient sleep or requiring room lighting.
• Hardware Privacy Mode — Disables video and audio transmission at the device level; a dedicated privacy indicator light confirms the mode is active, supporting HIPAA-aligned clinical workflows.
• Anti-UV Housing — Camera housing is rated to withstand UV-C disinfection procedures, enabling use in operating rooms, isolation wards, and other high-disinfection environments.
• Built-in Omnidirectional Microphone — Captures ambient audio in the patient room and transmits to the nursing station, enabling audio monitoring without additional microphone infrastructure.
• 256 Preset Positions — Store clinically defined camera positions (e.g., face, wound site, IV line) and recall them instantly via RS-232, RS-422, or IP control.
• PoE+ Single-Cable Installation — IEEE 802.3at PoE+ eliminates a separate power drop at each camera position, simplifying installation in patient rooms and corridors.
• PTZ Management and AVer ViewCare Software — Included free; ViewCare is purpose-built for multi-room patient monitoring workflows from a central nursing station.
• 3-Year AVerCare Warranty — Coverage includes 24-hour advance replacement, reducing risk in mission-critical healthcare deployments.

Typical Applications

• Medical Facility — Patient monitoring in general wards, ICUs, isolation rooms, and behavioral health units where 24/7 remote observation is required without staff entry.
• Training Room — Medical simulation labs and clinical skills training spaces where instructor observation of student technique requires zoom-in capability without disrupting the scenario.

Technical Specifications
