AVer CAM570 4K Dual Lens PTZ Conferencing Camera
Product Overview
The AVer CAM570 is a 4K dual-lens PTZ conferencing camera designed to cover both presenter and audience perspectives from a single unit, reducing the number of cameras required in a conference room or training space. One wide-angle lens captures the full room or speaker area while the second lens handles close-up PTZ framing, and the camera's AI-driven auto-tracking logic switches between views based on detected motion and voice activity. The CAM570 connects via USB 3.0 for plug-and-play compatibility with Microsoft Teams, Zoom, and Webex, and outputs 4K video over HDMI. Built for huddle rooms through large boardrooms, it is designed to minimize setup complexity while providing professional image quality for hybrid meetings.
Product Description
The dual-lens architecture of the CAM570 addresses a common challenge in conference room design: a single PTZ camera cannot simultaneously show both the whole-room view and a tight presenter shot without switching. The CAM570 resolves this by combining a wide-angle fixed lens with a PTZ zoom lens in one enclosure, with onboard processing selecting or blending the appropriate view based on AI scene analysis. The wide lens provides an expansive field of view suitable for capturing all participants in smaller rooms, while the PTZ lens delivers up to 12x optical zoom for close-up coverage of speakers or content at the far end of the room. Video output is 4K UHD over both HDMI and USB 3.0, and the camera functions as a UVC device so no drivers are required for standard conferencing software. The CAM570 supports VISCA over IP control and RS-232 for integration with room control systems, and pan/tilt/zoom of the secondary lens is fully motorized. PoE+ (802.3at) power delivery is supported for simplified installation without a separate power supply. The camera includes AVer's AI-based framing and presenter tracking capabilities, which monitor speaker movement and automatically reframe to keep the active participant in shot.
| Capability | CAM570 |
|---|---|
| Lens Configuration | Dual (wide fixed + PTZ zoom) |
| Max Resolution | 4K UHD (3840×2160) |
| PTZ Optical Zoom | 12x |
| USB Output | USB 3.0 (UVC) |
| HDMI Output | Yes |
| PoE+ Support | Yes (IEEE 802.3at) |
| AI Auto-Framing | Yes |
Key Features
- Dual-Lens Architecture — Combines a wide-angle fixed lens for full-room coverage with a motorized PTZ zoom lens for close-up framing, eliminating the need for multiple cameras in most conference room deployments.
- 4K UHD Video Output — Delivers 3840×2160 resolution over both HDMI and USB 3.0, providing high-detail imagery for large displays and remote participant feeds.
- AI Auto-Framing and Presenter Tracking — Onboard AI detects speaker movement and voice activity to automatically select and reframe the appropriate lens view without manual PTZ control intervention.
- 12x Optical Zoom (PTZ Lens) — Covers a wide field of view down to a tight telephoto framing, suitable for tracking presenters across rooms of varying depth.
- USB 3.0 Plug-and-Play (UVC) — Recognized as a standard UVC camera device by Windows and macOS; works natively with Microsoft Teams, Zoom, Webex, and other major conferencing platforms without driver installation.
- PoE+ (802.3at) Powered — A single Cat5e/Cat6 cable delivers both data and power, simplifying installation in drop-ceiling or wall-mount positions.
- VISCA over IP and RS-232 Control — Integrates with Crestron, AMX, Extron, and other AV control systems for room automation and PTZ preset recall.
- HDMI and USB Simultaneous Output — Route video to a local display or capture card via HDMI while simultaneously feeding a connected computer via USB for conferencing software.
Typical Applications
- Conference rooms requiring full-room and presenter close-up coverage from a single camera position
- Huddle rooms where installation of multiple cameras is impractical
- Boardrooms with hybrid meeting requirements and room control system integration
- Training rooms where instructor tracking and participant views are needed simultaneously
- All-hands rooms requiring automated framing without a dedicated camera operator
- Government spaces needing simplified AV infrastructure with professional-grade image quality
Technical Specifications
| Specification | Detail |
|---|---|
| Lens Configuration | Dual lens (wide-angle fixed + 12x optical PTZ) |
| Video Resolution | 3840×2160 @ 30 fps (4K UHD); 1920×1080 @ 60/30 fps |
| Optical Zoom | 12x (PTZ lens) |
| Video Outputs | HDMI, USB 3.0 (UVC) |
| Control Protocols | VISCA, VISCA over IP, RS-232 |
| Power | PoE+ (IEEE 802.3at), DC 12V |
| AI Features | Auto-framing, presenter tracking, voice-activity detection |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Frequently Asked Questions
Q: How does the dual-lens system work in practice?
A: The CAM570 uses onboard AI to monitor both the wide-angle and PTZ lens views simultaneously. It detects the active speaker through motion and voice-activity cues and automatically switches the primary output to the most relevant framing — either the full-room wide view or a tighter presenter shot from the PTZ lens — without manual operator control.
Q: Is the CAM570 compatible with Microsoft Teams Rooms and Zoom Rooms certified setups?
A: The CAM570 connects via USB 3.0 as a UVC device and is compatible with Teams and Zoom conferencing software. For certified Teams Rooms or Zoom Rooms hardware bundles, verify current certification status with AVer or your AV integrator, as certification status may vary by platform version.
Q: Can the PTZ lens be manually controlled during a meeting?
A: Yes. When AI auto-tracking is disabled or overridden, the PTZ lens can be controlled manually via RS-232, VISCA over IP, or an IR remote. Preset positions can be stored and recalled for fixed-scene framing.
Q: What PoE standard does the CAM570 require?
A: The CAM570 requires PoE+ (IEEE 802.3at), which supplies up to 30W. Standard PoE (802.3af, 15.4W) is not sufficient. Confirm that your network switch or PoE injector supports 802.3at before deployment.
Q: Does the CAM570 output both lenses simultaneously?
A: The camera outputs a single composited or selected video stream over USB and HDMI. The AI logic determines which lens view — or a combination of views using picture-in-picture — is presented as the primary output at any given time.
