RF Venue COMB8CP-ARC – 8-Channel IEM Pack with White CP Architectural Antenna

Product Overview

The RF Venue COMB8CP-ARC is a complete 8-channel in-ear monitor system bundle pairing the COMBINE8 IEM transmitter combiner with the white CP Architectural Antenna for fixed venue installations. The CP Architectural Antenna delivers the circular polarization performance of the CP Beam in a slim-profile enclosure designed for permanent wall or ceiling mounting. This bundle is the standard IEM transmitter solution for installed AV environments — houses of worship, conference centers, theaters — where an exposed stand-mounted antenna is architecturally unacceptable.

Product Description

The CP Architectural Antenna extends RF Venue’s circularly polarized antenna technology into an architectural form factor. Its slim-profile white enclosure mounts flush to walls or ceilings with a pre-drilled rear mounting plate, integrating into the room as discreetly as a smoke detector. The rear-mounted BNC female connector accommodates in-wall or in-ceiling cable runs for a completely concealed installation. Like the CP Beam, it uses circular polarization to maintain consistent signal strength as IEM receiver packs rotate on performers, eliminating the polarization dropout that affects linearly polarized antennas.

The COMBINE8 receives signals from up to eight IEM transmitters of any brand (50 mW or less) via BNC inputs and combines them into a single output feeding the CP Architectural Antenna. An LED indicator activates when any input exceeds +5 dBm, aiding system setup. The COMBINE8’s DC Octopus cable delivers 12 VDC to up to 8 compatible IEM transmitters, eliminating individual wall warts from the rack.

The white CP Architectural Antenna enclosure can be painted with standard latex paint to match any interior color scheme. The included 25-foot white RG8X coaxial cable is color-matched to maintain the clean aesthetic of a white-interior installation. The COMBINE8 operates in the 470–608 MHz band (USA/CAN) with a maximum input power of +18 dBm (60 mW) per channel. The CP Architectural Antenna accepts the combined signal from the COMBINE8 output for transmission to performers.

Key Features

• CP Architectural Antenna (White) — Slim-profile circular-polarized antenna for permanent wall or ceiling mounting; nearly invisible in light-colored interiors.
• Paintable Enclosure — White housing accepts standard latex paint for color-matching to any interior finish.
• Rear-Mounted BNC Connector — Supports in-wall/in-ceiling cable runs for completely concealed wiring.
• COMBINE8 8-Channel IEM Combiner — Combines up to 8 IEM transmitter signals; LED overload indicator; max +18 dBm (60 mW) per input.
• DC Octopus Power Distribution — Powers up to 8 IEM transmitters from the COMBINE8, eliminating wall warts.
• Circular Polarization — Consistent IEM signal regardless of performer orientation.
• Brand-Agnostic — Compatible with any IEM transmitter at 50 mW or less in the UHF TV band.
• White Cable Included — 25' white RG8X coaxial cable color-matched to the antenna for clean installations.

What's in the Box

• 1x CP Architectural Antenna (White) with rear-mount wall/ceiling plate and BNC rear connector
• 1x COMBINE8 8-Channel IEM Transmitter Combiner
• 1x 25' RG8X coaxial cable (white)
• 8x BNC jumper cables
• 1x DC Octopus 8-Connector Power Distribution Cable
• 1x AC power cable

Typical Applications

Suitable for:

• Houses of worship with installed IEM systems and white-interior sanctuaries
• Conference centers and multi-purpose venues with permanent IEM infrastructure
• Auditoriums and performing arts centers with concealed antenna requirements
• Broadcast studios with ceiling-mounted antenna distribution
• Commercial meeting spaces where visible antennas are architecturally unacceptable

Technical Specifications

Frequently Asked Questions

How does the CP Architectural Antenna compare to the CP Beam?

Both use circularly polarized technology for consistent IEM signal coverage. The CP Beam is a stand-mounted directional antenna with 9 dBd gain and a 70-degree forward beam for longer range applications. The CP Architectural Antenna is a flood-coverage antenna in a slim, paintable enclosure for permanent wall or ceiling installation where aesthetics are the priority. For fixed installed systems, the CP Architectural Antenna is the standard choice.

Can the antenna be painted after installation?

Yes. The enclosure is designed to accept standard latex paint. The antenna will continue to function normally after painting, allowing exact color-matching to the installation surface.

Does this bundle work with any IEM brand?

Yes. The COMBINE8 accepts any IEM transmitter operating at 50 mW or less in the 470–608 MHz UHF band (USA/CAN). This includes Shure PSM systems, Sennheiser EW-IEM, Lectrosonics, and others.

Can in-wall cable routing be used with this antenna?

Yes. The CP Architectural Antenna features a rear-mounted BNC female connector, allowing the coaxial cable to be routed through the wall behind the mounting plate for a fully concealed installation.

Is the COMB8CP-ARCB the same bundle with a black antenna?

Yes. The COMB8CP-ARCB is identical to the COMB8CP-ARC except the CP Architectural Antenna is black-finish. All other components and specifications are the same.

What warranty covers this product?

RF Venue components are covered by a manufacturer warranty. Contact Creation Networks at creationnetworks.net for support.
