Audio-Technica ATW-A410P UHF Powered Wideband Antenna (470 to 990 MHz)

Product Overview

The Audio-Technica ATW-A410P UHF powered wideband antenna is engineered for AV integrators improving wireless microphone reception across permanent installations. Covering a wide 470 to 990 MHz range, this low-profile UHF antenna mounts cleanly to a wall or ceiling and includes a switchable amplifier to compensate for cable loss. It is a sound choice for facilities deploying a remote antenna for wireless microphones in larger rooms. The design balances discreet aesthetics with the gain control needed for reliable RF performance.

Product Description

The ATW-A410P is a low-profile UHF antenna designed to mount unobtrusively on a wall or ceiling, making it well suited to boardrooms, auditoriums, and houses of worship where appearance matters. It operates across a 470 to 990 MHz range, giving integrators broad compatibility with wideband UHF wireless microphone systems. A 4-position switchable amplifier provides -10 dB, 0 dB, +6 dB, or +12 dB of gain, allowing technicians to compensate for losses introduced by long antenna cable runs.

An LED indicator displays the current gain setting, simplifying setup and confirmation during commissioning. To accommodate a range of installation environments, the antenna's BNC cable can be configured to exit from the top, side, or rear of the housing, which helps with clean cable management behind walls or above ceilings. The antenna ships with a mounting bracket and four screws for straightforward installation. The amplifier requires +12V DC bias power, supplied by a compatible receiver or antenna distribution system. Integrators planning a remote antenna deployment can review compatible wireless components and distribution gear at Creation Networks. Positioned correctly, the ATW-A410P helps extend usable range and improve reception consistency for UHF wireless microphones.

Key Features

• Low-Profile Mounting — Mounts discreetly to a wall or ceiling for clean integration in finished spaces.
• Wide UHF Range — Operates across 470 to 990 MHz for broad compatibility with wideband UHF wireless systems.
• 4-Position Gain Selector — Offers -10 dB, 0 dB, +6 dB, and +12 dB settings to compensate for cable loss.
• LED Gain Indicator — A built-in LED displays the current gain setting for fast confirmation during setup.
• Flexible Cable Routing — The BNC cable can exit from the top, side, or rear of the antenna for tidy installations.
• Included Mounting Hardware — Ships with a mounting bracket and four screws for straightforward installation.

Typical Applications

• Boardrooms requiring discreet, ceiling-mounted antennas
• Auditoriums extending wireless microphone coverage
• Houses of worship with large platform areas
• Conference rooms and multi-purpose rooms with long cable runs
• Government and commercial meeting spaces needing reliable RF reception
• Broadcast studios deploying remote UHF antennas

Technical Specifications

Specifications sourced from Audio-Technica (audio-technica.com).

Frequently Asked Questions

What frequency range does the ATW-A410P cover?

The antenna operates across a wide 470 to 990 MHz range, making it compatible with most wideband UHF wireless microphone systems within that band.

Why does the antenna have a switchable amplifier?

The 4-position gain selector (-10 dB, 0 dB, +6 dB, +12 dB) lets technicians compensate for signal loss introduced by long antenna cable runs, helping maintain reliable reception.

How does the antenna receive power?

The amplifier requires +12V DC bias power at 60 mA or less, typically supplied through the coaxial cable by a compatible receiver or antenna distribution system.

How does it integrate into an AV system?

The ATW-A410P connects via a BNC-J connector with 50-ohm impedance and is intended to feed a compatible UHF receiver or antenna distributor. The cable can exit from the top, side, or rear for clean routing within walls or ceilings.

What is included for installation?

Each antenna ships with a mounting bracket and four screws, and the low-profile housing is designed to mount discreetly on a wall or ceiling.

What warranty and support are available?

This is a genuine Audio-Technica product covered by the manufacturer's standard warranty. For warranty details or help specifying a compatible RF distribution system, contact the Creation Networks team.
