Atlona PTZ Camera with USB (White) - AT-HDVS-CAM-W

Product Overview

The Atlona AT-HDVS-CAM-W is an enterprise-grade PTZ camera with USB output designed for soft codec video conferencing, lecture capture, and distance learning in commercial AV environments. Featuring a USB 2.0 interface with standard UVC 1.1 driver compatibility, this PTZ conference room camera integrates with any PC-based video conferencing platform without proprietary software, including Microsoft Teams, Zoom, Cisco Webex, and Slack. The AT-HDVS-CAM-W delivers 1080p video at up to 30 Hz from a 1/2.8-inch HD CMOS sensor with 10x optical zoom, and supports H.264/H.265 IP streaming over RTMP and RTSP protocols for flexible deployment in huddle rooms, training rooms, and commercial meeting spaces. Available in white for installations where camera finish must match white wall or ceiling surfaces.

Product Description

The Atlona AT-HDVS-CAM-W is the white-finish variant of the professional HDVS-CAM PTZ camera, engineered for video conferencing and collaborative applications in commercial meeting spaces, classrooms, and training environments. It connects to any PC via USB 2.0 and is recognized as a standard UVC 1.1 (USB Video Class) device, ensuring compatibility with all major soft codec and unified communications clients without requiring proprietary drivers. The camera delivers high-quality imaging through a 1/2.8-inch low-noise HD CMOS sensor with 2.07 effective megapixels, supporting video resolutions from 176x144 up to 1080p at 30 Hz. The 10x optical zoom lens with a 60.9-degree wide-angle field of view and 6.43-degree telephoto field of view covers a wide range of room sizes and presenter positions. Pan and tilt ranges of plus or minus 170 degrees horizontal and -30 to +90 degrees vertical accommodate nearly any installation geometry. Camera control is available via TCP/IP, RS-232, USB, or the included handheld IR remote, and the camera supports VISCA, Pelco-D, and Pelco-P protocols for integration with professional AV control systems. Up to 255 camera presets can be stored, with 10 directly accessible from the IR remote. H.264 and H.265 streaming over IP is supported via RTMP and RTSP, enabling integration with lecture capture platforms and remote monitoring applications. The AT-HDVS-CAM-W integrates with Atlona Omega Series and OmniStream systems for complete AV and USB extension in automated conferencing environments. It has been tested and validated for compatibility with Barco ClickShare Conference for BYOM applications. The white finish makes this model particularly suitable for installations in rooms with white walls, suspended ceilings, or light-colored AV furniture where a black camera body would be visually prominent. The camera ships with a wall mount bracket and can be inverted for ceiling installation using the optional AT-HDVS-CAM-CMNT ceiling mount kit.

Key Features

• USB 2.0 Interface with UVC 1.1 Driver — Universal PC compatibility with all major soft codec platforms including Microsoft Teams, Zoom, Cisco Webex, Slack, and GoToMeeting without proprietary drivers.
• White Finish — Matches white wall, ceiling tile, and AV furniture finishes for discreet, professional installations.
• 1080p Video at 30 Hz — High-quality 1080p output from a 1/2.8-inch low-noise HD CMOS sensor with 2.07 effective megapixels.
• 10x Optical Zoom — Multi-element zoom lens with 60.9° wide-angle and 6.43° telephoto field of view; focal length 4.7–47 mm.
• Full Pan/Tilt/Zoom Control — Pan range ±170°, tilt range -30° to +90°; pan speed 0.1–180°/sec, tilt speed 0.1–80°/sec.
• Multiple Control Interfaces — TCP/IP, RS-232, USB, and IR control; supports VISCA, Pelco-D, and Pelco-P protocols.
• Camera Presets — Stores up to 255 presets; 10 accessible directly from the included handheld IR remote control.
• H.264 / H.265 IP Streaming — RTMP and RTSP protocol support for integration with lecture capture and remote streaming platforms.
• Auto Focus, White Balance, and Exposure — Fast and accurate auto focus with auto white balance and auto exposure modes for consistent image quality.
• Web-Based Configuration — Integrated web server provides GUI-based setup and camera control without additional software.
• Atlona Ecosystem Integration — Works with Atlona Omega Series and OmniStream for complete USB and AV extension in automated conferencing systems.
• Barco ClickShare Validated — Tested and validated for compatibility with Barco ClickShare Conference for BYOM conferencing applications.
• Flexible Mounting Options — Wall mount bracket included; optional AT-HDVS-CAM-CMNT ceiling mount kit available; 1/4-20 UNC tripod thread compatible.

Typical Applications

• Conference room
• Huddle room
• Boardroom
• Training room
• Multi-purpose room
• All-hands room
• Commercial meeting space
• House of worship
• Government space

Technical Specifications

Frequently Asked Questions

Q: Does the AT-HDVS-CAM-W require a proprietary driver?

No. The camera uses the standard UVC 1.1 (USB Video Class) driver built into Windows, macOS, and Linux operating systems. It is recognized automatically by the host PC without any additional software installation.

Q: How does the white version differ from the black AT-HDVS-CAM?

The AT-HDVS-CAM-W is identical in all technical specifications to the AT-HDVS-CAM. The only difference is the white enclosure finish, which is suited to installations where a black camera would be visually prominent against white ceilings, walls, or AV furniture.

Q: Which video conferencing platforms are compatible?

The AT-HDVS-CAM-W is compatible with any soft codec or UC platform that accepts a standard USB camera, including Microsoft Teams, Zoom, Zoom Rooms, Cisco Webex, Slack, and GoToMeeting. Zoom Rooms also supports USB-based PTZ camera control for preset recall.

Q: What is the maximum video resolution?

The AT-HDVS-CAM-W outputs video at up to 1080p at 30 Hz over USB. Lower resolutions are available from 176x144 up to 1080p, all selectable within the conferencing application or camera control interface.

Q: Can the camera stream over IP without a USB connection?

Yes. The AT-HDVS-CAM-W supports H.264 and H.265 video streaming over a standard IP network using RTMP and RTSP protocols, enabling integration with lecture capture systems, recording platforms, and remote monitoring applications independently of USB.

Q: How is the camera controlled in a professional AV system?

The camera supports TCP/IP, RS-232, USB, and IR control interfaces. PTZ control protocols include VISCA, Pelco-D, and Pelco-P, enabling integration with third-party control processors. Up to 255 camera presets can be stored and recalled programmatically.

Q: What mounting options are available?

The AT-HDVS-CAM-W ships with a wall mounting bracket for standard front-wall or rear-wall installation. For ceiling-mounted or inverted installations, the optional AT-HDVS-CAM-CMNT ceiling mount kit provides all necessary hardware. The camera base also features a standard 1/4-20 UNC tripod screw thread.

Q: Does this camera work with Atlona switchers and extenders?

Yes. The AT-HDVS-CAM-W is designed to work with Atlona Omega Series presentation switchers and OmniStream AV over IP systems for complete USB and AV extension in automated conferencing room designs. Visit creationnetworks.net for compatible Atlona system components.
