Atlas Sound TP2400 – Dual 12" 2-Way 200W RMS Cabinet Loudspeaker
Product Overview
The AtlasIED TP2400 is a dual 12" 2-way full-range cabinet loudspeaker rated at 200 watts RMS (400 watts peak) and designed for high-output portable and semi-permanent audio applications. It targets mobile DJs, musicians, and AV integrators who need a durable, high-SPL speaker for live reinforcement, events, and garage or studio monitoring. Long-tail applications include portable dual 12" DJ speaker for live events, high-output cabinet speaker for mobile PA, and 400-watt peak loudspeaker for music reinforcement.
Product Description
The TP2400 uses dual 12" woofers tuned with dual low-frequency ports to deliver extended bass response and high SPL output from a compact cabinet format. A 1" horn-loaded tweeter with a 13" x 6" horn provides wide horizontal dispersion and high-frequency projection at elevated volume levels, maintaining vocal intelligibility at concert and event sound pressure levels. The 4Ω impedance and 200W RMS / 400W peak power handling make this speaker suitable for use with a wide range of professional power amplifiers. The MDF enclosure is constructed for durability, resisting the resonance and panel vibration that degrades sound quality in lightweight enclosures. A stainless steel grille protects the drivers from physical damage during transport and live use. Aviation-grade carpet covering provides a durable, tear-resistant exterior finish. Integrated sure-grip carry handles on both sides allow two-person transport without additional accessories. Rugged corner braces protect the cabinet during stacking and transit, and they interlock when units are stacked, providing stability in multi-cabinet configurations. 5-way binding posts and a 1/4" input jack support connection to a wide range of power amplifier output types. The unit is designed for portable use and can be set up quickly without specialized mounting hardware.
Key Features
- Dual 12" Woofers — High-excursion woofer pair delivers strong mid and low frequency output suited for music reinforcement and DJ applications.
- 1" Horn-Loaded Tweeter — 19mm tweeter with 13" x 6" horn provides wide-dispersion high-frequency reproduction at high output levels.
- 200W RMS / 400W Peak — 4Ω impedance with substantial power handling for use with professional power amplifiers.
- Dual Low-Frequency Ports — Tuned ports extend bass response and improve efficiency at low frequencies.
- Durable MDF Enclosure — Dense MDF construction resists resonance and panel flex at high drive levels.
- Stainless Steel Grille — Protects drivers from physical impact during transport and live performance use.
- Aviation-Grade Carpet — Durable, tear-resistant exterior finish designed for repeated transport and use.
- Interlocking Corner Braces — Rugged braces protect enclosure corners and interlock when units are stacked for stability.
- 5-Way Binding Posts + 1/4" Jack — Flexible input connectivity compatible with most professional amplifier outputs.
- Integrated Carry Handles — Sure-grip side handles simplify transport and positioning.
Typical Applications
- Auditorium
- Multi-purpose room
- House of worship
- All-hands room
Technical Specifications
| Specification | Value |
|---|---|
| Model | TP2400 |
| Configuration | 2-way, dual 12" woofers |
| Woofer | Dual 12" |
| Tweeter | 19mm / 1" with 13" x 6" horn |
| Power (RMS) | 200W |
| Power (Peak) | 400W |
| Impedance | 4Ω |
| Sensitivity | 91 dB (2.83V/1m) |
| Ports | Dual low-frequency reflex ports |
| Inputs | 5-way binding posts, 1/4" jack |
| Height | 39.5" (100.33 cm) |
| Width | 15.25" (38.74 cm) |
| Depth | 15.75" (40.01 cm) |
| Enclosure | MDF with aviation-grade carpet |
| Grille | Stainless steel |
| Warranty | 60 months |
Frequently Asked Questions
Q: Does the TP2400 include a built-in amplifier?
A: No. The TP2400 is a passive loudspeaker requiring a separate power amplifier. Use an amplifier capable of driving a 4Ω load at 200W RMS or higher.
Q: Can two TP2400 units be stacked?
A: Yes. The interlocking corner braces are designed to stabilize stacked units during live use and transport.
Q: What input connections does the TP2400 accept?
A: The TP2400 has 5-way binding posts and a 1/4" input jack, covering the most common amplifier output connector types.
Q: What is the impedance of the TP2400?
A: The nominal impedance is 4Ω. Verify that your power amplifier is rated to drive a 4Ω load before connecting.
Q: Is the TP2400 suitable for outdoor use?
A: The TP2400 is not rated for permanent outdoor exposure. It is designed for indoor live performance, DJ, and event use. For temporary outdoor events, protect from direct rain exposure.
Q: What is the sensitivity rating?
A: The TP2400 is rated at 91 dB sensitivity (2.83V/1m), indicating relatively high efficiency for use with moderate-power amplifiers.
