Atlas Sound AT35-RM – Rack Mount 70.7V 35W Attenuator 3dB Steps
Atlas Sound AT35-RM – Rack Mount 70.7V 35W Attenuator 3dB Steps is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Atlas Sound AT35-RM – Rack Mount 70.7V 35W Attenuator 3dB Steps
Product Overview
The Atlas Sound AT35-RM is a deluxe rack-mounted 70.7V, 35-watt audio attenuator designed for installation in AV equipment racks, consoles, and cabinets. It provides 27dB of total attenuation in precise 3dB steps, giving system operators direct volume control over 70-volt distributed audio zones. UL listed and rated for 25V/70V systems, it is a standard choice for commercial sound system installations requiring accessible zone level control from the rack.
Product Description
The AT35-RM is purpose-built for rack panel mounting, offered without a wall plate so it can be installed directly into a standard rack panel assembly. AtlasIED's ATPLATE-052 rack plate accommodates up to six AT35-RM units side by side, allowing multi-zone level management from a single rack space when paired with that accessory. The front face features an attractive matte black polycarbonate dial scale overlay with adhesive backing, replacing the standard mounting plate for a clean, professional appearance. A skirted black knob is included and sized for confident manual operation. The overlay measures 29 square millimeters (51mm), fitting within standard rack panel cutouts. Attenuation is designed in make-before-break switching steps for uninterrupted audio during level adjustments. Safety listings include UL813 and UL2043, confirming suitability for both commercial audio and plenum-rated installations where applicable. The 60-month warranty makes this attenuator a dependable long-term component in permanent AV infrastructure.
Key Features
- Rack Panel Mount Design — No mounting plate required; fits directly into rack panels and consoles.
- 70.7V/25V Compatibility — Operates on both 70-volt and 25-volt distributed audio systems.
- 35W Power Rating — Handles up to 35 watts for coverage of standard commercial audio zones.
- 27dB Total Attenuation in 3dB Steps — Precise, consistent level control across the full range.
- Matte Black Polycarbonate Overlay — Clean, professional rack appearance with adhesive backing installation.
- Multi-Unit Rack Plate Compatible — Up to six units mount on the ATPLATE-052 rack plate.
- UL813 & UL2043 Listed — Certified for commercial audio and plenum environments.
- 60-Month Warranty — Backed by AtlasIED's extended warranty program.
Technical Specifications
| Specification | Value |
|---|---|
| Power Rating | 35W |
| Total Attenuation | 27dB |
| Step Size | 3dB |
| System Voltage | 25V / 70.7V |
| Height | 2 3/4" (6.99 cm) |
| Width | 1 3/4" (4.45 cm) |
| Depth | 2 1/8" (5.40 cm) |
| Shipping Weight | 1.00 lb (0.45 kg) |
| Safety Listed | UL813, UL2043 |
| Warranty Period | 60 months from date of purchase |
