Atlas Sound AT100-RM – Rack-Mount 70.7V 100W Attenuator 3dB Steps
Product Overview
The Atlas Sound AT100-RM is a 100-watt, 70.7V rack-mount attenuator designed for installation in AV equipment racks, cabinets, and consoles where centralized volume control of distributed speaker zones is required. It provides 27dB of total attenuation in 3dB increments, offering precise level management for commercial paging and background music systems. Up to six AT100-RM units can be mounted on the optional Atlas ATPLATE-052 rack plate, enabling multi-zone control in a single rack space.
Product Description
The AT100-RM is the rack-mount variant of the Atlas Sound AT series commercial attenuator line, purpose-built for 70.7V distributed audio systems. Unlike wall-plate attenuators, the AT100-RM is configured for panel mounting inside equipment racks, consoles, and AV cabinets, centralizing volume control for zones that may not have accessible wall locations. The unit ships without a mounting plate, instead including an attractive matte black polycarbonate dial scale overlay with adhesive backing and a skirted black knob for a clean finish when installed in a rack panel cutout. The overlay measures 29mm square for a compact footprint on the panel. The AT100-RM delivers 100W power handling on 25V or 70V distributed systems, and its 27dB total attenuation range in 3dB steps provides enough range for most zone-level balancing tasks. Safety listings include UL 813 and UL 2043, making it appropriate for plenum-adjacent installations where fire rating is a consideration. The AT100-RM is compatible with the HX23 dial scale overlay for retrofitting existing installations. CAD drawings are available for rack panel layout planning.
Key Features
- 100W / 70.7V Rating — Handles up to 100 watts on 25V or 70.7V distributed audio systems.
- 27dB Total Attenuation — 3dB step increments allow precise zone-level control in commercial paging and background music systems.
- Rack-Mount Configuration — Mounts directly in rack panel cutouts; up to six units fit on the optional ATPLATE-052 rack plate.
- Matte Black Polycarbonate Overlay — Adhesive-backed dial scale overlay and skirted black knob provide a clean finished appearance on the rack panel.
- UL 813 and UL 2043 Safety Listed — Compliant for use in systems requiring safety certification including plenum-rated installations.
- HX23 Retrofit Compatibility — Accepts the HX23 dial scale overlay for upgrading existing AT series installations.
- 25V and 70V Operation — Compatible with both common distributed audio voltage standards.
Technical Specifications
| Specification | Value |
|---|---|
| Model | AT100-RM |
| Power Rating | 100W |
| System Voltage | 25V / 70.7V |
| Total Attenuation | 27dB (in 3dB steps) |
| Height | 2 3/4" (6.985 cm) |
| Width | 1 3/4" (4.445 cm) |
| Depth | 2 1/2" (6.35 cm) |
| Shipping Weight | 1.50 lbs (0.68 kg) |
| Safety Listed | UL 813, UL 2043 |
| Warranty Period | 60 months from date of purchase |
