Atlas Sound FAP63T-W – 6.5" 2-Way In-Ceiling Speaker 70V/100V (Pair, White)

Product Overview

The Atlas Sound FAP63T-W is a 6.5-inch coaxial 2-way in-ceiling loudspeaker from the Strategy III series, sold and priced in pairs. Engineered for commercial background music and paging deployments requiring high speech intelligibility and wide audience coverage, the FAP63T-W supports 70.7V/100V and 8-ohm operation with a 150-watt power rating. Its patented Safety First Mounting System and UL1480/UL2043 dual certification make it the correct choice for drop-tile and drywall ceiling installations in plenum air-handling spaces across retail, hospitality, corporate, and institutional environments.

Product Description

The FAP63T-W Strategy III builds on AtlasIED's well-established Strategy series platform with performance and installation improvements at each generation. The driver complement pairs a 6.5-inch woofer with a 1-inch silk dome tweeter in a 2-way coaxial configuration, delivering a frequency response of 50 Hz to 20 kHz with 90 dB sensitivity and a dispersion pattern up to 110 degrees. A ported enclosure enhances low-frequency response for fuller sound in background music applications. The improved waveguide design provides wider and more uniform coverage than prior models, which can reduce speaker count per zone and lower overall system cost. The patented Safety First Mounting System (SFMS) uses integrated T-handles on the front baffle to secure mounting tabs — a mechanism tested across over 100 prototypes to eliminate over-torque damage during installation. This system also reduces installation time by up to 60% and requires no tools. Front-mounted 70V tap selection allows on-the-fly system tuning without removing the speaker. A 4-pole removable Euro-style (Phoenix) connector simplifies pre-wiring and daisy-chaining to additional speakers or subwoofers. No metal screws secure the doglegs, eliminating corrosion concerns in humid environments. The FAP63T-W ships in white and carries UL1480 and UL2043 dual safety listings. A 5-year limited warranty is included.

Key Features

• Patented Safety First Mounting System — T-handle dogleg system prevents over-torque damage; installs in drop tile or drywall without a drill or screwdriver.
• 70.7V/100V and 8Ω Operation — Front-mounted tap selector with transformer bypass for direct 8-ohm coupled operation.
• 150W Power Rating — Handles demanding commercial audio loads in large zones.
• Up to 110° Dispersion — Improved waveguide reduces speaker count while maintaining uniform coverage.
• Ported Enclosure — Optimized low-frequency tuning port delivers enhanced bass definition for music applications.
• 4-Pole Euro-Style Connector — Removable Phoenix connector supports easy pre-wiring and daisy-chaining of additional speakers or subwoofers.
• UL1480 and UL2043 Listed — Dual safety listing qualifies for plenum air-handling space installations.
• Corrosion-Free Mounting — No metal screws on doglegs; suitable for humid or climate-variable environments.
• 5-Year Warranty — Industry-standard limited warranty from AtlasIED.

Typical Applications

• Retail stores and restaurants requiring background music with paging capability
• Hotel lobbies, conference rooms, and convention centers
• Corporate meeting spaces and all-hands rooms
• Multi-purpose rooms and training rooms
• House of worship fill and overflow zones
• Commercial meeting spaces and boardrooms

Technical Specifications

Frequently Asked Questions

Q: Are these sold individually or as a pair?

A: The FAP63T-W is sold and priced as a pair. Each package contains two speakers.

Q: Can this speaker be used in plenum air-handling spaces?

A: Yes. The FAP63T-W is UL2043 listed, qualifying it for installation in plenum and air-handling ceiling spaces.

Q: What tools are needed for installation?

A: The Safety First Mounting System allows installation without a drill or screwdriver. A 9.18" cutout tool is needed for the ceiling opening.

Q: Does the speaker support 8-ohm direct coupling?

A: Yes. The front-mounted tap selector includes a transformer bypass setting for 8-ohm direct coupled operation.

Q: Can I daisy-chain multiple speakers?

A: Yes. The 4-pole removable Phoenix-style connector supports easy pre-wiring and daisy-chaining to additional Strategy series speakers and subwoofers.

Q: Is the FAP63T-W compatible with existing Strategy series enclosures?

A: The FAP63T-W uses the C-ring/V-rail tile bridge mounting system included with the speaker, compatible with standard drop-tile and drywall ceiling construction.
