ASHLY WR-1.5 Wall Remote, single rotary potentiometer + 4-position rotary select

Product Overview

The Ashly WR-1.5 is a passive wall remote providing a single rotary potentiometer for DC level (volume) control plus a 4-position rotary selector switch for source or preset selection, fitting standard North American wall boxes. The WR-1.5 is the appropriate Ashly passive remote when a single zone requires both volume control and the ability to select one of four sources or presets from a wall location, without requiring a networked or serial remote.

Product Description

The Ashly WR-1.5 passive wall remote fits standard North American wall boxes and connects to compatible Ashly amplifiers and processors using low-gauge wiring. It provides a single rotary potentiometer for DC level (VCA gain) control of a zone, and a separate 4-position rotary selector switch for source or preset recall. This combination makes the WR-1.5 the practical choice for commercial spaces where end users need both volume control and simple source or scene selection from the same wall plate—without the complexity of a programmable serial or network remote. The passive design means no separate power supply or data wiring is required; all control is handled over low-gauge wire from the WR-1.5 to the Ashly product. Visual indication confirms when changes are registered by the connected Ashly amplifier or processor.

Key Features

• Single Rotary Potentiometer — DC level (VCA gain) control for the connected zone or channel.
• 4-Position Rotary Selector — Source or preset recall selection from up to four options at the wall location.
• Passive Design — No separate power supply required; connects via low-gauge wire to compatible Ashly products.
• Standard North American Wall Box — Fits standard wall boxes for clean architectural integration.
• Visual Change Confirmation — Indicator confirms control changes have been registered.

Technical Specifications
