ASHLY NE8250PED Network Amplifier with Dante Option Card

Product Overview

The Ashly NE8250PED is a network-enabled 8-channel power amplifier delivering 250W per channel at 4 ohms, featuring Protea Embedded DSP on all inputs and outputs plus a factory-installed OPDante option card for Dante audio network connectivity. This NE Series network amplifier is built for commercial AV installations where integrators need a complete DSP amplifier, matrix mixer, and digital audio network interface in a single 2U rack-mount unit. With 2000W total RMS output, a full Protea DSP audio processor, and standard Ethernet control, the NE8250PED addresses multi-zone distributed audio, paging, and conference room sound reinforcement without the need for separate outboard processing. The unit supports both 120V and 230V AC input, making it suitable for North American and international installations.

Product Description

The Ashly NE8250PED network power amplifier leverages Ashly's NE Series platform, which uses standard 10/100 Ethernet for control and monitoring through Protea NE software without requiring proprietary control hardware. The OPDante option card provides Dante AoIP connectivity, allowing audio to be delivered over the facility's IP network from any Dante-compatible source. Protea Embedded DSP on every input and output channel delivers full signal processing capability including EQ, dynamics, delay, crossover, and routing, eliminating the need for a separate DSP processor in the signal chain. With 8 channels at 250W into 4 ohms, the NE8250PED drives a wide range of commercial loudspeaker systems, and DC voltage control of the input attenuators provides straightforward remote volume management from wall remotes or building automation systems. Preset recall capability allows the amplifier to switch between different configuration states for varying room uses or time-of-day scheduling. LED indicators for power, standby, protection, and network communications provide at-a-glance status, while per-channel four-step signal meters, bridge mono, temperature, and current indicators support field troubleshooting. Physical dimensions of 3.5" x 19" x 15.5" fit standard 2U rack space at 19.7 lbs, making it practical for both equipment room racks and in-ceiling enclosures. RoHS certification confirms compliance with environmental standards for commercial product installations.

Key Features

• 8 x 250W at 4 Ohm Output — 2000W total RMS for driving commercial loudspeaker arrays in low-impedance configurations.
• OPDante Card Included — Factory-installed Dante option card for direct AoIP audio delivery over IP networks.
• Protea Embedded DSP — Full DSP suite on all inputs and outputs including EQ, dynamics, delay, and crossover.
• Standard Ethernet Control — 10/100 Ethernet for Protea NE software remote control; no proprietary controller required.
• DC Voltage Volume Control — Remote attenuator control via DC voltage input for integration with wall remotes and building automation.
• Preset Recall — Multiple presets for adapting the system to different room configurations or uses.
• Remote Power Standby — Network or contact-closure standby for energy management in unoccupied spaces.
• Class-D Amplifier — High-efficiency switching amplifier topology reduces heat dissipation in equipment rooms.
• Universal AC Input — Accepts 120V and 230V AC for North American and international deployments.
• RoHS Compliant — Meets environmental compliance requirements for commercial product installations.

Typical Applications

• Conference rooms and boardrooms requiring network-controlled audio
• Commercial meeting spaces with multi-zone audio needs
• Training rooms and multi-purpose facilities
• Hotel ballrooms and event spaces
• House of worship audio distribution
• Government and institutional facilities

Technical Specifications

Frequently Asked Questions

Is the Dante card included or an optional add-on for the NE8250PED?

The OPDante card is factory-installed. The NE8250PED ships ready for Dante audio network deployment without any additional hardware purchases.

What is the difference between the NE8250PED and the NE8250.70PED?

The NE8250PED is configured for low-impedance (4 ohm) speaker connections, while the NE8250.70PED is optimized for 70V constant-voltage distributed speaker systems. Choose based on your speaker system type.

Does the NE8250PED include a DSP processor?

Yes. Protea Embedded DSP is built into all input and output channels, providing complete signal processing capability within the amplifier unit. No separate DSP device is required for standard installations.

What software is used to program the NE8250PED?

Ashly Protea NE software connects via standard Ethernet. The software provides access to all DSP parameters, routing, preset storage, and system monitoring functions.

Can the NE8250PED be controlled from a wall panel or room controller?

Yes. DC voltage input to the input attenuators allows volume control from wall remotes such as the Ashly WR-5. GPI ports enable preset recall from contact-closure devices and room automation systems.

What rack space does the NE8250PED require?

The unit occupies 2U of rack space (3.5" tall) and is 15.5" deep, fitting standard 19" equipment racks.
