APC Smart-UPS SUA750DR1 750VA 120V DIN Rail
Product Overview
The APC Smart-UPS SUA750DR1 is a 750VA DIN rail-mount UPS for 120V commercial automation, control system, and light industrial installations, providing battery backup and automatic voltage regulation for control panel components mounted on standard 35mm DIN rails. Designed for building automation systems, commercial control panels, and light industrial environments where traditional rack-mount UPS units are not practical, this unit installs directly on DIN rails in equipment enclosures without additional mounting hardware. Suitable for protecting PLCs, building management system gateways, and control system components in North American 120V commercial deployments.
Product Description
The SUA750DR1 addresses commercial AV and building automation deployments where control system components are housed in DIN rail enclosures — a common configuration in commercial building installations integrating AV control with HVAC, lighting, and access control systems. At 750VA with 120V input and output, it protects the combined load of a control processor, I/O modules, and communication gateways in a single control panel. The DIN rail mount eliminates the need for rack space or tower placement, making it practical for wall-mount control enclosures and compact building automation panels. Automatic voltage regulation stabilizes output during brownouts and overvoltages common in commercial building electrical systems without depleting battery reserve. Battery backup provides protection time for safe equipment shutdown or brief utility interruptions common in commercial construction environments.
Key Features
- DIN Rail Mounting — Direct 35mm DIN rail installation without additional hardware.
- 750VA Capacity — Protects control processors and I/O modules in commercial panels.
- 120V Input/Output — North American commercial system compatibility.
- Automatic Voltage Regulation — Stable output during utility fluctuations.
- Battery Backup — Protects against brief utility interruptions and enables safe shutdown.
- Compact Design — Minimal DIN rail space consumption in control enclosures.
Typical Applications
- Commercial building automation and BMS control panel UPS
- AV control system interface panels in commercial installations
- Light industrial PLC and automation component backup
- HVAC and lighting control system power protection
Technical Specifications
| Specification | Value |
|---|---|
| Model | SUA750DR1 |
| Capacity | 750VA |
| Input Voltage | 120V |
| Output Voltage | 120V |
| Form Factor | DIN Rail Mount (35mm) |
| Topology | Line-Interactive |
| Warranty | 2 Years |
Frequently Asked Questions
- Can the SUA750DR1 protect a commercial AV control processor in a DIN rail enclosure?
- Yes. The SUA750DR1 is appropriate for protecting AV control processors, I/O modules, and communication gateways mounted on DIN rails in commercial building automation and AV control panels on 120V systems.
- What is the difference between the SUA750DR1 and SUA1000DR1?
- The SUA1000DR1 provides 1000VA of capacity for larger control panel loads. The SUA750DR1 is appropriate for smaller panels with fewer or lower-draw control components.
- Does the SUA750DR1 require any tools for installation on a DIN rail?
- The SUA750DR1 snaps onto standard 35mm DIN rails without tools. Follow APC's installation guide for proper orientation and clearance requirements in the control enclosure.
