APC Smart-UPS On-Line SRT8KXLT 8000VA Tower 208V
Product Overview
The APC Smart-UPS On-Line SRT8KXLT is an 8000VA / 7200W double-conversion on-line UPS in a tower chassis with 208V NEMA output, providing maximum-capacity zero-transfer-time power protection for broadcast master control rooms, large command centers, and enterprise AV equipment rooms on 208V circuits without rack infrastructure. This unit continuously regenerates clean 208V power with complete galvanic isolation, making it appropriate for the largest and most demanding commercial AV systems requiring on-line topology in non-rack deployments. SmartSlot accepts optional NMC, and external SRT 192V battery packs scale runtime for 24/7 operations.
Product Description
The SRT8KXLT at 8000VA / 7200W is specified for broadcast production and command center environments where a single 208V tower UPS must carry the combined load of multiple high-draw systems — broadcast routing matrices, video processing infrastructure, servers, and large-scale AV distribution. Non-rack equipment rooms, purpose-built technology spaces, and production facilities without rack enclosures are the primary deployment contexts. Double-conversion on-line topology eliminates transfer time and provides complete isolation from utility power disturbances including transients, harmonics, and frequency variations critical for broadcast-grade AV equipment. Internal bypass maintains power to connected equipment during UPS maintenance. External APC SRT 192V battery packs scale runtime for always-on commercial operations. SmartSlot accepts optional NMC for SNMP and enterprise monitoring.
Key Features
- 8000VA / 7200W Capacity — Maximum 208V tower on-line capacity for broadcast and command center deployments.
- Double-Conversion On-Line Topology — Zero transfer time and complete 208V galvanic isolation.
- 208V Input/Output, NEMA Receptacles — North American 208V commercial equipment.
- Tower Form Factor — Non-rack equipment room installation.
- Internal Bypass — Continuous power during UPS maintenance.
- Scalable Runtime — External APC SRT 192V battery packs.
- SmartSlot — Optional NMC for enterprise monitoring.
Technical Specifications
| Specification | Value |
|---|---|
| Model | SRT8KXLT |
| Capacity | 8000VA / 7200W |
| Topology | Double-Conversion On-Line |
| Input Voltage | 208V |
| Output Voltage | 208V |
| Form Factor | Tower |
| Internal Bypass | Yes |
| SmartSlot | Yes (optional NMC) |
| External Battery | Compatible with APC SRT 192V battery packs |
| Warranty | 2 Years |
Frequently Asked Questions
- Is this unit suitable for a broadcast master control room?
- Yes. The SRT8KXLT provides 8000VA / 7200W of double-conversion 208V on-line protection suitable for broadcast master control infrastructure in non-rack equipment room configurations.
- What is the IEC receptacle equivalent?
- The SRT8KXLT-IEC provides the same capacity and topology with IEC 309 output receptacles. Both are listed on creationnetworks.net.
