APC Smart-UPS On-Line SRT3000XLT-5KTF 3000VA Tower 208/240V to 120V Step-Down Transformer

Product Overview

The APC Smart-UPS On-Line SRT3000XLT-5KTF is a 3000VA / 2700W double-conversion on-line UPS in a tower chassis with 208/240V input and an integrated 5kVA step-down transformer providing 120V output, designed for commercial AV deployments where 208/240V power is available at the distribution panel but connected equipment requires 120V. This unit eliminates the need for a separate step-down transformer by integrating voltage conversion directly into the UPS, providing zero-transfer-time on-line protection with 120V pure sine wave output from 208/240V input in a single chassis.

Product Description

The SRT3000XLT-5KTF addresses a common challenge in commercial AV deployments in facilities with 208/240V power distribution — the need to provide clean, protected 120V power to equipment that cannot be powered directly from 208/240V circuits. By integrating a 5kVA step-down transformer into the UPS chassis, this unit simplifies the power infrastructure for commercial AV technology closets, boardrooms, and command spaces where 208V is available at the panel but AV equipment requires 120V. At 3000VA / 2700W input with 120V output, it supports the combined 120V load of a substantial commercial AV installation. Double-conversion on-line topology provides zero transfer time and complete isolation from utility power quality events. External APC SRT battery packs extend runtime, and SmartSlot accepts optional NMC for enterprise monitoring.

Key Features

• Integrated 5kVA Step-Down Transformer — Converts 208/240V input to 120V output without a separate transformer.
• 3000VA / 2700W Capacity — Substantial 120V load capacity for commercial AV deployments.
• Double-Conversion On-Line Topology — Zero transfer time on-line protection.
• Tower Form Factor — Technology closet and equipment room installation.
• 208/240V Input — For facilities with 208/240V commercial power distribution.
• 120V Output — Standard North American AV and IT equipment compatibility.
• Scalable Runtime — External APC SRT battery packs.
• SmartSlot — Optional NMC for enterprise monitoring.

Typical Applications

• Commercial AV technology closets on 208V distribution requiring 120V equipment power
• Boardroom and conference room AV powered from 208V panels
• Command center 120V AV equipment on 208/240V circuits
• Mixed-voltage commercial AV and IT deployments

Technical Specifications

Frequently Asked Questions

Why would I need this instead of a standard 208V UPS?

Specify the SRT3000XLT-5KTF when your facility's power distribution is 208/240V but your commercial AV equipment operates on 120V. The integrated step-down transformer eliminates the need for a separate transformer, simplifying the power infrastructure and reducing installation cost.

Is the step-down transformer rated for continuous AV loads?

Yes. The 5kVA transformer is rated for continuous commercial AV and IT loads within its capacity. Ensure the combined 120V load of connected equipment does not exceed the transformer's 5kVA rating.

Is a rackmount version available?

Yes. The SRT3000RMXLT-5KTF provides the same UPS and step-down transformer combination in a 2U rackmount chassis. Both are listed on creationnetworks.net.
