APC Smart-UPS On-Line SRT3000RMXLT-5KTF 3000VA Rackmount 208V to 120V 2U Step-Down Transformer
APC Smart-UPS On-Line SRT3000RMXLT-5KTF 3000VA Rackmount 208V to 120V 2U Step-Down Transformer is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
APC Smart-UPS On-Line SRT3000RMXLT-5KTF 3000VA Rackmount 208V to 12...
Product Overview
The APC Smart-UPS On-Line SRT3000RMXLT-5KTF is a 3000VA / 2700W double-conversion on-line UPS in a 2U rackmount chassis with 208/240V input and an integrated 5kVA step-down transformer providing 120V output, combining zero-transfer-time on-line protection with built-in voltage conversion for commercial AV and IT rack installations in facilities with 208/240V power distribution and 120V equipment. The 2U rackmount chassis installs in standard 19-inch racks, eliminating the need for a separate external step-down transformer in the rack. SmartSlot accepts optional NMC for enterprise monitoring.
Product Description
The SRT3000RMXLT-5KTF is specified for commercial AV and IT rack deployments in facilities where 208/240V circuits serve rack locations but equipment requires 120V — common in commercial construction with three-phase electrical distribution. The integrated 5kVA step-down transformer converts 208/240V input to 120V output directly within the 2U UPS chassis, consolidating UPS and transformer into a single rack unit. At 3000VA input with double-conversion on-line topology, it provides zero transfer time and complete isolation for connected 120V equipment. External APC SRT battery packs extend runtime, and SmartSlot accepts optional NMC for enterprise monitoring.
Key Features
- Integrated 5kVA Step-Down Transformer — 208/240V to 120V conversion in the UPS chassis.
- 3000VA / 2700W Capacity — Mid-high capacity rackmount on-line protection with voltage conversion.
- Double-Conversion On-Line Topology — Zero transfer time and complete isolation.
- 2U Rackmount — Standard 19-inch rack installation without separate transformer.
- 208/240V Input / 120V Output — For 208V rack locations with 120V AV equipment.
- Scalable Runtime — External APC SRT battery packs.
- SmartSlot — Optional NMC for enterprise monitoring.
Technical Specifications
| Specification | Value |
|---|---|
| Model | SRT3000RMXLT-5KTF |
| Capacity (Input) | 3000VA / 2700W |
| Step-Down Transformer | 5kVA, 208/240V to 120V |
| Topology | Double-Conversion On-Line |
| Input Voltage | 208/240V |
| Output Voltage | 120V |
| Form Factor | 2U Rackmount |
| SmartSlot | Yes (optional NMC) |
| Warranty | 2 Years |
