AMX Jetpack JPK-1300 - 3x1 4K Switching, HDBaseT Transport & Control Kit
AMX Jetpack JPK-1300 - 3x1 4K Switching, HDBaseT Transport & Control Kit is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or just need expert advise? Give us a call at 1-888-230-3661 or LiveChat below. Purchasing 1 or 100, there may be greater savings beyond the advertised price.
AMX Jetpack JPK-1300 - 3x1 4K Switching, HDBaseT Transport & Co...
The AMX Jetpack JPK-1300 is a cost-effective, all-in-one AV kit for K-12 classrooms and small-to-medium meeting spaces, integrating 4K60 HDMI/USB-C switching, HDBaseT transport, room control, wallplate access, and a 2x25W amplifier with no programming required. It delivers secure, reliable operation via panel buttons, RS-232, Telnet, SSH, Web GUI, or Jetpack Manager app, supporting multiple video sources, embedded audio, ARC, CEC, and campus-wide management. Key benefits include crystal-clear voice lift through amplification/de-embedding, extended reach up to 40m at 4K or 70m at 1080p over shielded Cat 6/6A/7 cable, and USB pass-through for smart-board connectivity, making it ideal for education and hospitality venues needing affordable, multi-functional AV.
Built with durable metal chassis for rack or tabletop deployment, the kit includes a keypad-style transmitter (UA: 116x114x39.2mm; EK: 146x85x39.2mm) and receiver (250x30x104mm), weighing 0.35-0.81kg per component, featuring PoC from receiver for simplified powering and low 80W BTU/hr dissipation.
Suited for classrooms, meeting rooms, and hybrid learning, it enables applications like multi-source switching, audio routing, and display control. Fully compatible with HDMI 2.0/HDCP 2.2 sources/displays, USB-C devices, and AMX NetLinx systems.
Features Chart
| Feature | Benefit |
|---|---|
| 4K60 HDMI 2.0 & HDCP 2.2 | Supports high-resolution video up to 4096x2160@60Hz for sharp, lag-free content |
| 2x HDMI + 1x USB-C Inputs | Enables switching between laptops, document cameras, and USB-C devices without adapters |
| HDBaseT Transport | Transmits lossless 4K video & audio up to 40m (131ft) or 1080p up to 70m (230ft) over single Cat cable |
| Built-in 2x25W Amplifier | Provides voice lift and background audio for clear sound in larger classrooms |
| USB Pass-Through Hub | Simplifies smart-board connections with 2x1 USB-C/B hosting and 220Mbps bandwidth |
| Comprehensive Audio Suite | Includes mic/line input, line out, ARC, de-embedding, and remote mute for flexible routing |
| Power over Cable (PoC) | Single power supply at receiver powers entire system, reducing cabling and installation time |
| Web GUI & Jetpack Manager | Allows easy configuration and campus-wide device management without programming |
Specifications Table
| Specification | Detail |
|---|---|
| Video Inputs | 2x HDMI (HDMI/HDCP), 1x USB-C (HDMI/HDCP) |
| Video Outputs | 1x HDMI (HDMI/HDCP) |
| Video Resolution | Up to 4096x2160@60Hz (4:2:0); full list in datasheet |
| Audio Inputs | Embedded on HDMI/USB-C (2-CH L-PCM), 1x MIC/LINE analog at RX |
| Audio Outputs | 2x25W (4/8Ω) amp out, 2-CH line level analog out |
| USB Bandwidth | Max 220Mbps |
| Ports (TX) | 2x HDMI Type A, 1x USB-C, 1x USB-B host, 1x Micro USB (prog), 2x RJ-45 (AV & control) |
| Ports (RX) | 1x HDMI out, 1x USB-A device, 1x Micro USB (prog), 1x 3.5mm IR out, 2x RJ-45 (LAN & AV), RS-232, relays, remote mute, audio out, amp out, mic/line in |
| Environmental | Operating: 0–40°C, 20–90% RH (non-condensing); Storage: -20–60°C |
| Power | PoC from RX; typical 80W BTU/hr dissipation |
| Compliance | FCC Part 15 Class B, EN 55032/55035, UL 62368-1, RoHS/REACH, UKCA, Prop65, HETMA |
| Dimensions (UA) | Keypad: 70x114x22.2mm; TX: 116x114x39.2mm; RX: 250x30x104mm |
| Dimensions (EK) | Keypad: 146x85x22.2mm; TX: 146x85x39.2mm; RX: 250x30x104mm |
| Weight (UA) | Keypad: 0.19kg, TX: 0.35kg, RX: 0.81kg |
| Weight (EK) | Keypad: 0.23kg, TX: 0.33kg, RX: 0.81kg |
| Models | JPK-1300-UA (US/AU), JPK-1300-EK (EU/UK) |
