Allied Telesis AT-IE210L-18GP-60 – 16-Port Industrial Managed PoE+ Switch 2x SFP
Allied Telesis AT-IE210L-18GP-60 – 16-Port Industrial Managed PoE+ Switch 2x SFP is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Allied Telesis AT-IE210L-18GP-60 – 16-Port Industrial Managed PoE+ ...
Product Overview
The Allied Telesis IE210L-18GP-60 is an Allied Telesis IE210L industrial managed PoE+ switch with 16 ports, designed for cost-effective industrial Ethernet deployments in environments with extended operating temperatures from 0°C to 65°C. Positioned below the IE340 series in the Allied Telesis industrial portfolio, the IE210L-18GP-60 delivers essential industrial-grade switching with Layer 2 managed features and PoE+ at a lower price point, making it the right choice for manufacturing, retail, building automation, and other lite industrial applications where full Layer 3 routing is not required. The unit provides 16x 10/100/1000Base-T PoE+ copper ports and 2x SFP uplinks for fiber backhaul connectivity.
Product Description
The Allied Telesis IE210L industrial managed PoE+ switch 16-port model supports a total PoE budget of 247W, enabling simultaneous powering of all 16 connected devices at up to 30W per port (PoE+). The 2x SFP uplink ports support both 100Base-FX and 1000Base-X fiber transceivers, providing flexible backhaul options. Running AlliedWare Plus, the IE210L-18GP-60 includes comprehensive Layer 2 features including IEEE 802.1Q VLANs, MSTP/RSTP spanning tree, IEEE 802.3ad LACP link aggregation, and QoS. EPSRing and ITU-T G.8032 ERPS (via optional feature license AT-FL-IE2L-L2-1) provide sub-50ms ring failover for resilient industrial topologies. Autonomous Management Framework Plus (AMF Plus) enables zero-touch provisioning, automated configuration backup, and centralized policy management across the entire AMF network. OpenFlow v1.3 support (via optional license) provides SDN readiness for forward-looking network deployments. The 0°C to 65°C operating range handles elevated-temperature industrial environments without forced-air cooling. IEEE 802.1X port authentication and dynamic VLAN assignment secure network access, while ACL-based traffic filtering protects against unauthorized traffic flows. The desktop and optional rack-mount form factor (with AT-RKMT-J13 kit) gives installation flexibility.
Key Features
- 16x 10/100/1000Base-T PoE+ (IEEE 802.3at) — Up to 30W per port, 247W total PoE budget for 16 devices.
- 2x SFP Uplinks (100FX / 1000X) — Dual-speed fiber uplinks for flexible backhaul to aggregation switches.
- 0°C to 65°C Operating Temperature — Extended-temperature design for manufacturing, retail, and building automation environments.
- AlliedWare Plus OS — Enterprise-class Layer 2 management with VLANs, MSTP, LACP, QoS, and ACLs.
- AMF Plus Management — Zero-touch provisioning and centralized network management via Autonomous Management Framework Plus.
- EPSRing / G.8032 ERPS (Optional License) — Sub-50ms ring recovery for resilient industrial network topologies.
- OpenFlow v1.3 Ready (Optional License) — SDN-capable for software-defined industrial network architectures.
- Cost-Effective Industrial Switching — IE210L series delivers industrial-grade durability at lower cost than the IE340 series where Layer 3 routing is not required.
Typical Applications
- Manufacturing and factory automation — PoE-powered sensors, HMIs, and IP cameras in temperature-controlled industrial zones
- Retail and hospitality — PoE-powered IP phones, access points, and POS systems in commercial buildings
- Building digitalization — Smart building sensors, access control systems, and BAS/BMS integration
- Industrial IoT edge — Connecting and powering IoT devices at the network edge in extended-temperature environments
- Small-scale industrial ring networks — EPSRing/G.8032 for resilient connectivity in modular production cells
Technical Specifications
| Specification | Value |
|---|---|
| Model | AT-IE210L-18GP-60 |
| Copper PoE+ Ports | 16x 10/100/1000Base-T IEEE 802.3at PoE+ |
| Uplink Ports | 2x SFP (100FX / 1000Base-X) |
| Total Ports | 18 |
| PoE Budget | 247W total |
| PoE per Port | Up to 30W (PoE+) |
| Layer Support | Layer 2 (managed) |
| Switching Fabric | 36 Gbps |
| Forwarding Rate | 26.8 Mpps |
| Operating Temperature | 0°C to 65°C |
| Management | CLI, SNMP, Web GUI, AMF Plus |
| Ring Protocols | EPSRing, ITU-T G.8032 (optional license) |
| SDN | OpenFlow v1.3 (optional license) |
| Dimensions (H x W x D) | 42.5 x 341 x 275 mm (1.73" x 13.42" x 9.09") |
| Weight | 3.0 kg (6.6 lb) |
| Form Factor | Desktop / Rack-mountable (with AT-RKMT-J13) |
| Operating System | AlliedWare Plus |
Frequently Asked Questions
- Q: What is the difference between the IE210L-18GP-60 and the IE340-20GP-80?
- The IE210L-18GP-60 is a Layer 2 managed switch with a 0°C to 65°C rating, suitable for lighter industrial environments at lower cost. The IE340-20GP-80 is a full Layer 3 switch rated -40°C to +75°C, intended for harsher environments with routing requirements, a higher PoE budget, and 4x SFP+ uplinks.
- Q: What is the total PoE budget of the IE210L-18GP-60?
- The IE210L-18GP-60 provides a 247W total PoE budget across 16 ports, supporting simultaneous 30W PoE+ delivery to up to 8 ports, or 15.4W (PoE) across all 16 ports concurrently.
- Q: Does the IE210L-18GP-60 support ring network protocols?
- Yes, with the optional AT-FL-IE2L-L2-1 Layer 2 Premium license, the switch supports EPSRing Master mode, VLAN translation, Q-in-Q, UDLD, and PTP Transparent Mode. G.8032 ERPS requires the separate AT-FL-IE2-8032 license.
- Q: What does the -60 suffix in the part number indicate?
- The -60 suffix indicates the power supply variant. The AT-IE210L-18GP-60 includes the internal power supply unit appropriate for the specified PoE budget.
- Q: Can the IE210L-18GP-60 be rack-mounted?
- Yes. While the base unit ships as a desktop form factor, the optional AT-RKMT-J13 rack-mount kit enables standard 19-inch rack installation.
- Q: Where can I purchase the AT-IE210L-18GP-60?
- The AT-IE210L-18GP-60 is available through Creation Networks at creationnetworks.net, an authorized Allied Telesis reseller.
