Allied Telesis AT-XS916MXS-10 – 12-Port SFP+ 10G Stackable Switch
Allied Telesis AT-XS916MXS-10 – 12-Port SFP+ 10G Stackable Switch is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Allied Telesis AT-XS916MXS-10 – 12-Port SFP+ 10G Stackable Switch
Product Overview
The Allied Telesis XS916MXS 10G SFP+ stackable switch delivers cost-effective, high-density fiber connectivity for enterprise server and storage environments. Designed for the XS900MX series, this 1U managed Layer 3 switch provides 12 SFP/SFP+ slots for 10G fiber uplinks combined with 4 copper 100/1000/10GBase-T RJ-45 ports — making it the ideal 10G core aggregation switch or enterprise campus access layer switch. IT managers seeking a high-port-density 10G fiber switch with VCStack support will find the AT-XS916MXS-10 well suited to wiring closet and data center edge deployments.
Product Description
The AT-XS916MXS-10 is part of Allied Telesis's XS900MX series, purpose-built for enterprise networks that require dense 10G fiber connectivity in a compact 1U form factor. With 12 SFP/SFP+ expansion slots supporting both 1G SFP and 10G SFP+ transceivers, this switch accommodates a broad range of fiber media — including single-mode and multimode — for flexible campus and data center cabling. Four integrated 100/1000/10GBase-T RJ-45 ports provide copper connectivity for servers, storage, or upstream aggregation switches. The Allied Telesis Management Framework (AMF) simplifies day-to-day operations through centralized management, auto-backup, auto-upgrade, auto-provisioning, and auto-recovery, reducing reliance on specialized network engineering staff. VCStack technology allows two XS900MX switches to operate as a single logical unit via 10G SFP+ direct-attach cables, provisioning up to 28 x 10G ports in a single rack unit with automatic failover. EPSRing protection creates resilient ring topologies with recovery in under 50ms, supporting high-availability enterprise deployments. Layer 3 switching enables IP routing between VLANs without a separate router. Available from Creation Networks, the AT-XS916MXS-10 is backed by Allied Telesis's enterprise support programs.
Key Features
- 12 x SFP/SFP+ Slots — Support both 1G SFP and 10G SFP+ transceivers for fiber connectivity over single-mode or multimode cable.
- 4 x 100/1000/10GBase-T RJ-45 Ports — Copper ports for servers, storage, or uplink connections at speeds up to 10Gbps.
- VCStack Support — Stack two XS900MX switches using 10G SFP+ DAC cables, presenting up to 28 x 10G ports as a single virtual switch.
- Layer 3 Switching — Full inter-VLAN IP routing without a separate routing device.
- EPSRing Resilience — Ethernet Protection Switching Ring enables sub-50ms recovery in ring topologies.
- Allied Telesis Management Framework (AMF) — Zero-touch provisioning, auto-backup, auto-upgrade, and centralized management across the entire AMF network.
- 1U Rack-Mountable — Compact form factor fits standard 19-inch racks; 5.95 lb, 1.7" x 12.7" x 8.3".
- Manageable — Full CLI, SNMP, and web GUI management support.
- Optical Fiber and Twisted Pair Media — Supports both media types for maximum deployment flexibility.
- TUV Certified — Meets international safety and environmental standards.
Typical Applications
- Enterprise campus core or aggregation switch with high-density 10G fiber ports
- Data center top-of-rack switch connecting servers and storage via SFP+
- Wiring closet distribution switch in a VCStack high-availability configuration
- 10G relay switch with fiber uplinks for multi-building campus networks
- Server/storage interconnect in small to mid-size enterprise environments
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | AT-XS916MXS-10 |
| Product Series | XS900MX |
| Product Line | CentreCOM |
| SFP/SFP+ Expansion Slots | 12 |
| RJ-45 Copper Ports | 4 x 100/1000/10GBase-T |
| Layer Support | Layer 3 |
| Ethernet Technology | Gigabit Ethernet, 10 Gigabit Ethernet |
| Network Technology | 10GBase-X, 10GBase-T |
| Media Supported | Optical Fiber, Twisted Pair |
| Stacking | VCStack (2 units, up to 28 x 10G ports) |
| Management | AMF, CLI, SNMP, Web GUI |
| Resiliency | EPSRing (sub-50ms failover) |
| Form Factor | 1U Rack-mountable |
| Dimensions (H x W x D) | 1.7" x 12.7" x 8.3" |
| Weight | 5.95 lb |
| Power Source | Internal Power Supply |
| Redundant PSU | No |
| Certifications | TUV |
| Modular | Yes |
| List Price | $3,525.00 |
Frequently Asked Questions
- Q: What is the difference between the AT-XS916MXS-10 and the AT-XS916MXT-10?
- The AT-XS916MXS-10 has 12 SFP/SFP+ fiber slots and 4 copper RJ-45 ports, making it the fiber-dominant model. The AT-XS916MXT-10 reverses this with 12 copper RJ-45 ports and 4 SFP/SFP+ slots, suited for copper-centric deployments.
- Q: Can I use 1G SFP transceivers in the SFP+ slots?
- Yes. The 12 expansion slots support both 1G SFP and 10G SFP+ transceivers, giving you backward compatibility with existing 1G fiber infrastructure.
- Q: How does VCStack work on the XS916MXS?
- Two AT-XS916MXS or AT-XS916MXT switches can be connected via 10G SFP+ direct-attach cables to form a VCStack. The two physical units appear as a single logical switch with up to 28 x 10G ports, managed from one IP address with automatic failover.
- Q: Does this switch support IP routing between VLANs?
- Yes. The AT-XS916MXS-10 supports Layer 3 switching, enabling inter-VLAN routing without requiring a separate router in the network path.
- Q: What management tools are available?
- The switch runs Allied Telesis Management Framework (AMF), which provides centralized management, auto-backup, auto-upgrade, auto-provisioning, and auto-recovery across the entire AMF network. CLI, SNMP, and web GUI access are also supported.
- Q: Is the AT-XS916MXS-10 suitable for a small data center?
- Yes. Its 12-port SFP+ density makes it well suited as a top-of-rack switch connecting servers and storage in a small to mid-size data center or as an aggregation switch in a larger enterprise campus.
- Q: Where can I purchase the AT-XS916MXS-10?
- The AT-XS916MXS-10 is available from Creation Networks at creationnetworks.net. Contact our team for volume pricing and configuration assistance.
