Allied Telesis AT-IMC200TP/SC-980 TAA 10/100TX TO 100FX/SC INDUSTRIAL TEMP FAST ENET POE+

Product Overview

The Allied Telesis AT-IMC200TP/SC-980 is a TAA-compliant industrial-grade media converter that bridges 10/100BASE-T (Fast Ethernet, 100Mbps) copper networks to 100BASE-FX fiber over an SC connector, with PoE+ (802.3at, 30W) output to power a connected device over the copper port. Rated for an extended industrial temperature range of -40°C to 75°C, it is designed for outdoor enclosures, factory floors, transportation infrastructure, and utility substations where standard commercial-grade equipment cannot operate reliably. This is a 100Mbps Fast Ethernet device — not a Gigabit converter — and should be selected specifically when 100FX fiber connectivity is required at the network edge alongside PoE+ device powering.

Product Description

The AT-IMC200TP/SC-980 converts between 10/100BASE-T twisted-pair copper and 100BASE-FX multi-mode fiber with an SC fiber connector, enabling network extension over fiber in environments where copper runs exceed distance limits or where electrical isolation between segments is required. The Allied Telesis industrial 100Base-T PoE+ media converter SC model provides 802.3at PoE+ at 30W on the copper port, allowing it to simultaneously power an attached 802.3at-compliant device such as a PTZ camera, wireless access point, or VoIP phone while converting the connection to fiber. For higher-power requirements, LTPoE++ supports 4-pair cabling at up to 70W. Note that this model operates at 100Mbps Fast Ethernet speeds; it is not a Gigabit media converter — buyers requiring Gigabit copper-to-fiber conversion should consider the Allied Telesis IMC2000TP/SC series. The fanless design eliminates mechanical failure points, contributing to the high-reliability requirement of industrial and outdoor deployments. Remote Power Cycle capability allows an administrator to reboot a connected PoE-powered device without physical access to the site, reducing truck roll costs. IP-30 protection guards against dust and contact with the converter's internal components. The -980 suffix indicates the US power cord variant with a standalone enclosure that mounts on a DIN rail or as a standalone unit.

Key Features

• Industrial Temperature Range — Operates from -40°C to 75°C, qualifying for outdoor cabinets, factory environments, and transportation ITS deployments.
• 100BASE-T to 100BASE-FX Conversion (SC) — Converts Fast Ethernet copper (10/100BASE-T) to 100Mbps multi-mode fiber with SC connector for distance extension and electrical isolation.
• PoE+ Output (802.3at, 30W) — Powers an 802.3at-compliant device on the copper port, eliminating the need for a separate power supply at the remote endpoint.
• LTPoE++ 4-Pair Support (up to 70W) — Higher-power mode for demanding edge devices over 4-pair cabling where standard 30W PoE+ is insufficient.
• Remote Power Cycle — Remotely reboot a connected PoE device without on-site intervention, saving time and operational cost in remote deployments.
• IP-30 Protection — Protects internal components from dust and contact in harsh physical environments.
• Fanless Design — No moving parts ensures silent, high-reliability operation with a reduced failure rate in industrial conditions.
• TAA Compliant — Meets Trade Agreements Act requirements for US government and federal procurement.
• DIN Rail or Standalone Mounting — Flexible physical installation in control panels, enclosures, or standalone on a shelf or bracket.

Typical Applications

• Outdoor and roadside ITS (intelligent transportation systems) fiber-to-copper edge connections
• Industrial automation and factory floor network fiber extension with PoE+ device powering
• Utility substation and water/power infrastructure remote terminal connectivity
• Transit and rail station IP camera and VoIP phone connections over existing fiber runs
• Building automation systems in environments with wide temperature swings
• Government and municipal networks requiring TAA-compliant industrial-grade networking

Technical Specifications

Frequently Asked Questions

Q: Is this a Gigabit or Fast Ethernet media converter?

The AT-IMC200TP/SC-980 is a Fast Ethernet (100Mbps) media converter. The copper port operates at 10/100BASE-T and the fiber port at 100BASE-FX. It does not support Gigabit speeds. For Gigabit copper-to-fiber conversion with PoE, consider the Allied Telesis IMC2000TP series.

Q: What does the SC fiber connector mean for this converter?

SC (Subscriber Connector) is a standard push-pull fiber optic connector widely used in enterprise and industrial networks. The AT-IMC200TP/SC-980 uses an SC connector on its 100BASE-FX fiber port and connects to multi-mode fiber cables terminated with SC connectors.

Q: Can this converter power a connected device via PoE?

Yes. The copper RJ-45 port provides 802.3at PoE+ at 30W, powering compliant devices such as IP cameras, wireless access points, and VoIP phones. For 4-pair LTPoE++ applications, up to 70W is available.

Q: What is the operating temperature range?

The AT-IMC200TP/SC-980 is rated from -40°C to 75°C (-40°F to 167°F), making it suitable for outdoor enclosures, transportation systems, and industrial environments where commercial equipment (typically 0°C to 40°C) would fail.

Q: What does Remote Power Cycle do?

Remote Power Cycle allows a network administrator to cut and restore PoE power to the connected device remotely over the network, effectively rebooting it without requiring a technician visit to the site. This is critical for managing cameras and access points in unmanned remote locations.

Q: Is the AT-IMC200TP/SC-980 TAA compliant?

Yes. The -980 suffix denotes the US power cord variant and the product is TAA compliant, making it eligible for US government and federal agency procurement.

Q: Can it be installed on a DIN rail?

Yes. The AT-IMC200TP/SC-980 supports both DIN rail mounting (common in industrial control panels and electrical enclosures) and standalone operation on any flat surface or in a compatible chassis.
