Allied Telesis AT-FL-XS9MX-01 XS900MX PREMIUM LICENSE
Software License
Allied Telesis AT-FL-XS9MX-01 XS900MX PREMIUM LICENSE is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Allied Telesis AT-FL-XS9MX-01 XS900MX PREMIUM LICENSE
Product Overview
The Allied Telesis AT-FL-XS9MX-01 is a software-only Premium License for the XS900MX series switches, delivering advanced routing and network automation capabilities via a single license key — no hardware is shipped. This license unlocks enterprise-class features including expanded OSPF and BGP routing tables, VRF-Lite, VXLAN support, and VLAN double tagging (Q-in-Q) on compatible Allied Telesis platforms. It is purpose-built for network engineers who need to scale Layer 3 functionality and multi-tenant segmentation on an existing XS900MX deployment. Activate the license on your switch through the AlliedWare Plus operating system; no physical installation is required.
Product Description
The AT-FL-XS9MX-01 is the Allied Telesis x950 license feature upgrade software that transforms the XS900MX switch into an enterprise-capable Layer 3 platform. Once applied, the Premium License unlocks OSPF (up to 16,000 routes), BGP4 (up to 5,000 routes), PIMv4 and PIMv6 multicast routing, OSPFv3, RIPng, VRF-Lite with up to 64 domains, VXLAN, VLAN double tagging (Q-in-Q), VLAN Translation, RADIUS-Full, and Unidirectional Link Detection (UDLD). These features collectively enable the XS900MX to operate as a full-featured distribution or core switch within enterprise and service provider networks. The license integrates seamlessly with Allied Telesis's AlliedWare Plus operating system and the Autonomous Management Framework Plus (AMF Plus) for centralized, automated network management. One license is required per stack member. This is a pure software entitlement — no physical media is included — making it a cost-effective path to unlocking advanced capabilities on hardware you already own. Available from Creation Networks with fast order processing and licensing support.
Key Features
- OSPF v2/v3 Routing — Supports up to 16,000 OSPF and 8,000 OSPFv3 routes for large-scale IPv4 and IPv6 deployments.
- BGP4 and BGP4+ Support — Enables up to 5,000 BGP4 (IPv4) and 5,000 BGP4+ (IPv6) routes for multi-homed or ISP-edge scenarios.
- VRF-Lite (64 Domains) — Creates up to 64 isolated routing domains on a single switch for multi-tenant network segmentation.
- VXLAN Overlay — Extends Layer 2 segments across Layer 3 boundaries to support virtualized data center and cloud environments.
- PIMv4 and PIMv6 Multicast — Full PIM-SM, PIM-DM, and PIM-SSM support for efficient multicast distribution in IPv4 and IPv6 networks.
- VLAN Double Tagging (Q-in-Q) — Enables carrier Ethernet and service provider use cases requiring stacked VLAN tags.
- RADIUS-Full Authentication — Extends RADIUS support for comprehensive AAA (authentication, authorization, and accounting) control.
- Software-Only Delivery — License key activated via AlliedWare Plus CLI; no hardware shipment required, with rapid deployment.
Typical Applications
- Enterprise core and distribution switch feature expansion on existing XS900MX hardware
- Multi-tenant campus and data center networks requiring VRF-Lite segmentation
- Service provider Ethernet deployments utilizing Q-in-Q VLAN stacking
- VXLAN-based overlay networks for virtualized server and cloud connectivity
- Networks requiring dynamic routing with OSPF, BGP, and multicast PIM protocols
- Government and regulated environments leveraging TAA-compliant Allied Telesis platforms
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | AT-FL-XS9MX-01 |
| License Type | Perpetual Software License |
| Product Type | Software Licensing |
| Compatible Platform | XS900MX Series (AlliedWare Plus) |
| Stack Licensing | One license per stack member |
| OSPF Routes (v2) | Up to 16,000 |
| BGP4 Routes | Up to 5,000 |
| VRF-Lite Domains | Up to 64 |
| Manufacturer | Allied Telesis, Inc. |
| Delivery Method | Electronic (no physical media) |
Frequently Asked Questions
- Q: What hardware does the AT-FL-XS9MX-01 license support?
- The AT-FL-XS9MX-01 is designed for the Allied Telesis XS900MX series switches running the AlliedWare Plus operating system. Confirm compatibility with your specific switch model before purchasing.
- Q: Is any hardware shipped with this license?
- No. This is a software-only license delivered as a license key. There is no physical media or hardware included in the order.
- Q: How do I activate the license on my switch?
- License activation is performed through the AlliedWare Plus CLI using the standard Allied Telesis license installation procedure. Refer to the AlliedWare Plus Software Reference for your platform for exact steps.
- Q: Do I need one license per switch in a stack?
- Yes. Stack licensing for the AT-FL-XS9MX-01 requires one license per stack member. Each physical unit in the stack must have its own license installed.
- Q: What routing protocols does the Premium License unlock?
- The license enables OSPF v2 (16,000 routes), BGP4 (5,000 routes), PIMv4 and PIMv6 multicast, OSPFv3, RIPng, and BGP4+, in addition to VRF-Lite, VXLAN, Q-in-Q VLAN tagging, and RADIUS-Full.
- Q: Is this license term-based or perpetual?
- The AT-FL-XS9MX-01 is a perpetual license. It does not expire and does not require annual renewal, unlike time-limited OpenFlow or AMF licenses.
- Q: Can I purchase this license through Creation Networks?
- Yes. Creation Networks (https://creationnetworks.net) is an authorized Allied Telesis reseller. Contact us for volume pricing and licensing support.
