Allied Telesis AT-CM301 – Converteon Fast Ethernet Fiber Converter Blade

Overview

The Allied Telesis AT-CM301 is a media converter blade for the AT-CV5001 18-slot Converteon chassis, converting 10/100BASE-TX copper to 100BASE-FX multimode fiber over an ST connector with a reach of up to 2km. Designed for centralized, chassis-based fiber conversion at scale, it allows organizations to manage multiple media converter blades in a single rack-mounted unit. The AT-CM301 is well-suited for campus and enterprise environments standardized on the Converteon platform.

Description

The AT-CM301 operates as a hot-swappable blade module within the AT-CV5001 Converteon chassis, which accommodates up to 18 converter blades in a single 1U rack space. This chassis-based approach centralizes fiber conversion for large deployments, reducing the cable clutter and management overhead of individual standalone converters. Each AT-CM301 blade handles one copper-to-fiber conversion: 10/100BASE-TX on the RJ-45 side to 100BASE-FX multimode on the ST fiber side, at distances up to 2km — appropriate for intra-building and inter-building campus runs.

The ST fiber connector is a dual-ferrule bayonet-style interface common in legacy enterprise and campus fiber plants. Organizations with existing ST-terminated multimode fiber infrastructure can deploy the AT-CM301 without re-terminating their fiber cabling. The AT-CM301 receives power and management connectivity from the AT-CV5001 chassis, with no separate power supply needed per blade. This design makes large-scale fiber conversion cost-effective and straightforward to maintain — individual blades can be replaced in the chassis without disrupting other conversion channels.

Key Features

• Chassis-Based Architecture: Installs as a blade in the AT-CV5001 18-slot Converteon chassis, enabling centralized management of up to 18 fiber conversion channels in 1U.
• 10/100BASE-TX to 100BASE-FX Conversion: Bridges copper Fast Ethernet to multimode fiber, extending reach up to 2km over ST-terminated fiber.
• ST Fiber Connector: Compatible with legacy ST-terminated multimode fiber infrastructure, avoiding costly re-termination.
• Hot-Swap Blade Replacement: Individual blades can be inserted or removed from the chassis without interrupting other channels in the same chassis.
• Chassis-Powered: Draws power directly from the AT-CV5001 chassis — no separate power adapter required per blade.
• Scalable Deployment: Add blades incrementally as conversion needs grow, up to the 18-slot maximum of the chassis.

Typical Applications

• Centralized Fast Ethernet fiber conversion in enterprise IDF/MDF rooms where multiple copper-to-fiber connections are managed from a single Converteon chassis.
• Campus backbone connectivity where copper-terminated edge devices connect to a 100BASE-FX multimode fiber ring or backbone via the Converteon platform.
• Organizations with existing ST-terminated multimode fiber plants who need to extend or expand Fast Ethernet connectivity without replacing fiber cabling.
• Large-scale deployments (education, healthcare, government campuses) requiring rack-efficient, manageable media conversion at scale.
