Allied Telesis AT-2711FX/ST-901 NIC 100FX/ST PCIE TAA ROHS LP & STD BRACKET INCL

Product Overview

The Allied Telesis AT-2711FX/ST-901 is a TAA-compliant 100Mbps Fast Ethernet PCIe fiber network interface card featuring an ST bayonet fiber connector. Installing in a PCIe x1 slot (compatible with x1, x4, x8, or x16 slots), this single-port 100Base-FX NIC adds fiber network connectivity to desktops, workstations, or servers that lack a fiber port. The ST connector version is the right choice for systems connecting to existing ST-terminated multimode fiber infrastructure. Both standard-height and low-profile brackets are included, making this card suitable for full-size towers and rack-mounted servers alike. RoHS and TAA compliant for federal procurement.

Product Description

The Allied Telesis AT-2711FX/ST-901 PCIe 100Base-FX fiber NIC with ST connector delivers 100Mbps Fast Ethernet connectivity over multimode fiber via an ST bayonet port installed on a low-profile PCIe x1 card. The ST connector — the defining difference between this card and the /LC-901 and MTRJ variants in the AT-2711FX series — makes this the correct model when connecting to existing ST-terminated fiber cabling, which remains prevalent in legacy enterprise campus networks, government facilities, and industrial environments. The PCI Express x1 interface provides up to 250 MB/s of host bus throughput between the NIC and motherboard, well exceeding the 100Mbps line rate and ensuring no bus-side bottleneck. A comprehensive Windows diagnostic and configuration utility is included, enabling administrators to perform detailed tests and analysis on the card and its network connection. The priority queuing capability allows fine-tuned control over traffic handling in multi-application environments. Upgrading from an older AT-2701FX PCI card to the AT-2711FX is a direct capability upgrade to PCIe without changing the fiber connector type or cable plant. Both standard-height and low-profile brackets are included in the box. Country of origin: Singapore. Available from Creation Networks at creationnetworks.net.

Key Features

• 100Base-FX with ST Connector — 100Mbps Fast Ethernet over multimode fiber via the ST bayonet connector; right for legacy ST-terminated fiber infrastructure.
• PCIe x1 Interface — Installs in any PCIe x1, x4, x8, or x16 slot; up to 250 MB/s host bus throughput.
• Low-Profile and Standard Brackets Included — Fits full-height towers and low-profile compact chassis; no additional bracket purchase required.
• Windows Diagnostic Utility — Comprehensive software for testing, diagnostics, and analysis of the adapter and its network connection.
• Priority Queuing — Traffic prioritization for QoS control in multi-application environments.
• TAA and RoHS Compliant — Meets Trade Agreements Act requirements for federal procurement; RoHS environmentally certified.
• PCIe Upgrade Path from AT-2701FX — Drop-in PCIe successor to the PCI-based AT-2701FX series without changing fiber connector type.

Typical Applications

• Adding 100Base-FX ST fiber connectivity to desktop workstations and servers via PCIe x1
• Connecting hosts to legacy ST-terminated multimode fiber campus infrastructure
• Federal and government deployments requiring TAA-compliant 100Mbps fiber NICs
• Upgrading existing PCI-based AT-2701FX installations to PCIe without recabling
• Industrial and enterprise environments where ST fiber remains the installed standard

Technical Specifications

Frequently Asked Questions

Q: What is the difference between the AT-2711FX/ST-901 and the AT-2711FX/LC-901?

Both cards are identical 100Mbps 100Base-FX PCIe fiber NICs. The only difference is the fiber connector: /ST-901 uses an ST bayonet connector, while /LC-901 uses an LC duplex connector. Choose based on the connector type on your existing fiber cable runs.

Q: Does the card fit in low-profile PCIe slots?

Yes. The AT-2711FX/ST-901 ships with both standard-height and low-profile brackets, making it compatible with full-size towers and compact or rack-mounted systems with low-profile expansion slots.

Q: Is this card a direct upgrade from the AT-2701FX?

Yes. The AT-2711FX series is the PCIe successor to the AT-2701FX PCI series. If you’re upgrading a system from PCI to PCIe and currently have ST fiber connections, the AT-2711FX/ST-901 preserves your existing cabling without any changes.

Q: What operating systems are supported?

The included Windows diagnostic utility confirms Windows support. Consult the Allied Telesis compatibility matrix for Linux and other OS driver availability.

Q: Is this card suitable for government or federal procurement?

Yes. The AT-2711FX/ST-901 is TAA compliant, qualifying it for GSA Schedule and federal procurement vehicles.
