Allen & Heath AH-M-DX32-PRIME-OUT-A PRIME Mic/Line Output Module - 8 XLR Inputs

Product Overview

The Allen & Heath AH-M-DX32-PRIME-OUT-A is a next-generation 8-channel D-A output module designed for the DX32 Modular Expander, delivering class-leading analog output quality for dLive, Avantis, and SQ mixing systems. Built around the latest 32-bit DAC technology in a fully balanced differential topology, the PRIME Output module sets a new standard for analog output fidelity in professional live sound and commercial AV deployments. It is the purpose-built solution for engineers who require the lowest possible noise floor and distortion on monitor outputs, amp racks, and broadcast feeds connected to Allen & Heath digital mixing systems. The module integrates directly into the DX32 expander and is optimized for use with Allen & Heath's 96kHz XCVI FPGA console core, making it ideal for high-channel-count dLive commercial installations requiring premium output performance.

Product Description

The PRIME Output module represents a complete redesign of the D-A output card architecture within the Allen & Heath DX32 platform. Where standard output modules prioritize channel count and reliability, the PRIME module prioritizes analog output integrity at every stage of the signal path, from converter selection through to the output connector.

Using 32-bit DAC technology and a fully balanced differential output stage, the module achieves ultra-low THD and noise figures that are immediately audible on high-SPL monitor systems and critical listening applications. Specially selected operational amplifiers and high-quality passive components — chosen for linearity, low noise, and long-term stability — are assembled with full metal shielding to reject RF interference throughout the circuit.

The PRIME Output module slots into any DX32 Modular Expander output bay and can be used standalone or combined with PRIME Input modules for a complete end-to-end high-fidelity signal chain. For touring engineers, broadcast teams, and commercial AV integrators who are already invested in the dLive or Avantis ecosystem, this module is a direct upgrade path that does not require any new infrastructure — simply install in the DX32 and immediately gain access to the next level of analog output quality.

The module is optimized specifically for use with Allen & Heath's 96kHz XCVI FPGA core, ensuring that the improved resolution of the console's processing stage is not lost at the analog output. For applications where every decibel of dynamic range matters — high-end monitor mixes, broadcast output buses, or mastering-quality recording feeds — the PRIME Output module delivers measurable, audible improvement over the standard DX32 output cards.

Key Features

• 32-Bit DAC Technology — Latest-generation converters deliver class-leading D-A performance for professional analog outputs
• Fully Balanced Differential Output Stage — Improved common mode rejection, reduced cross-talk, and enhanced linearity compared to standard output cards
• Ultra-Low THD and Noise — Specially selected op-amps and passive components chosen for exceptional audio performance
• Full Metal RF Shielding — Comprehensive shielding throughout the module eliminates RF-induced noise in demanding installation environments
• 96kHz XCVI FPGA Optimized — Designed specifically to complement Allen & Heath's high-resolution console core for end-to-end fidelity
• Compatible with DX32 for SQ, dLive, and Avantis — Drop-in installation into existing DX32 expander bays without any additional configuration
• 8 Balanced XLR Outputs per Module — High channel density for monitor, amp rack, and broadcast output requirements
• Combinable with PRIME Input Modules — Build a complete PRIME I/O system for maximum end-to-end signal quality

Typical Applications

• High-fidelity monitor output for touring and festival dLive systems
• Broadcast output feeds from Avantis or dLive consoles to OB vans and broadcast infrastructure
• Commercial AV installations requiring premium analog output quality from DX32 stage boxes
• House of worship systems where output quality on IEM and wedge mixes is critical
• Recording studio integration for high-quality direct outputs from dLive or SQ systems

Technical Specifications

Frequently Asked Questions

Which Allen & Heath consoles are compatible with the PRIME Output module?

The PRIME Output module is designed for use with the DX32 Modular Expander, making it compatible with dLive, Avantis, and SQ mixing systems that use the DX32 as a stage box or I/O expander.

Can the PRIME Output module be combined with the PRIME Input module?

Yes. PRIME Input and PRIME Output modules can be installed in the same DX32 for a complete end-to-end high-fidelity analog signal chain.

How many PRIME Output modules can be installed in a single DX32?

The DX32 accepts multiple output modules depending on bay configuration. Contact Creation Networks for a bill of materials specific to your system build.

Does the PRIME Output module require any special firmware or configuration?

No additional configuration is required beyond standard DX32 output routing. The module is detected automatically by the connected console.

What is the audible difference between the PRIME Output module and the standard DX32 output card?

The PRIME module offers measurably lower THD+N, improved dynamic range, and reduced cross-talk — differences that are most audible in monitor systems, broadcast feeds, and high-headroom amp rack connections.

Is the PRIME Output module suitable for permanent commercial AV installations?

Yes. The module is designed for both touring and installed environments. Its metal shielding and high-quality component selection make it well-suited to permanent rack installations.
