Allen & Heath AH-M-DANTE-A Module for iLive and GLD Mixing Systems

Product Overview

The Allen & Heath AH-M-DANTE-A is a factory-installed option card that adds Audinate Dante networking to iLive and GLD series mixing systems. It provides up to 64x64 channels of bi-directional digital audio across a standard IP network, enabling seamless integration with Dante-compatible amplifiers, stage boxes, preamps, and recording systems. Operating at either 48 or 96 kHz, the module bridges the iLive and GLD ecosystems into modern networked AV infrastructures. With locking EtherCON connectors and support for Dante Domain Manager, the M-DANTE-A is purpose-built for installations where signal integrity and network management are non-negotiable.

Product Description

The AH-M-DANTE-A slots into the expansion bay of iLive and GLD series mixers, converting them into fully Dante-capable network audio nodes. Three locking EtherCON ports handle the primary network connection, a redundant secondary link, and a control network bridge — providing both audio transport and system management over the same cabling infrastructure. The card supports switchable 48 or 96 kHz sample rates, making it compatible with both legacy and modern Dante networks without requiring additional hardware.

One of the standout capabilities of the M-DANTE-A is its support for digital splits, allowing the same audio feeds to be routed simultaneously to front-of-house, monitors, broadcast, and recording destinations with no signal degradation. Multitrack recording direct to a connected computer is achieved without additional converters, reducing system complexity in both permanent installations and touring rigs. The module is ready for Dante Domain Manager, giving IT administrators and AV system integrators centralized control over device enrollment, audio routing, and network segmentation.

For commercial AV integrators maintaining iLive or GLD systems in broadcast facilities, houses of worship, or large-venue installations, the M-DANTE-A provides a cost-effective path to Dante without replacing the host console. It preserves the existing investment in Allen & Heath hardware while delivering enterprise-grade network audio performance.

Key Features

• 64x64 Dante Audio Channels — Full bidirectional 64-channel audio over standard Cat5e/Cat6 Ethernet infrastructure
• Dual Sample Rate Support (48/96 kHz) — Switch between sample rates to match existing Dante network configurations
• Three Locking EtherCON Ports — Primary, secondary (redundant), and control network connections for robust, fault-tolerant operation
• Redundant and Switch Network Modes — Configurable port modes protect against single-link failures in mission-critical installations
• Internal Control Network Bridge — Allows system control traffic to share the same network infrastructure as audio
• Dante Domain Manager Ready — Supports enterprise-level Dante network management, device enrollment, and routing control
• Digital Split Capability — Route identical audio feeds to multiple destinations simultaneously without signal loss
• Multitrack Recording Support — Send 64 channels direct to a DAW over the network without additional hardware

Typical Applications

• Legacy iLive and GLD System Upgrades — Add Dante networking to existing Allen & Heath consoles without console replacement
• Broadcast Facilities — Distribute audio across facility networks with sample-accurate routing and redundancy
• Houses of Worship — Integrate mixing consoles with networked amplifiers, stage boxes, and recording systems
• Commercial AV Installations — Connect mixing systems to Dante-based distributed audio infrastructure
• Live Sound Production — Enable digital splits for FOH, monitors, and broadcast from a single source
• Multitrack Studio Recording — Capture 64 channels simultaneously to a connected DAW workstation

Technical Specifications

Frequently Asked Questions

Is the M-DANTE-A compatible with all iLive and GLD consoles?

The M-DANTE-A is designed for iLive and GLD series mixing systems. Verify your specific console model supports the expansion bay format before ordering. Contact us to confirm compatibility with your unit.

Can I use the M-DANTE-A on a network that runs 48 kHz if my console runs 96 kHz?

The card is switchable between 48 and 96 kHz, so you can match the sample rate to your existing Dante network without changing your console's internal operating rate.

Does the M-DANTE-A require Dante Domain Manager to function?

No. Dante Domain Manager is optional and provides advanced network management for enterprise environments. The module operates on standard Dante networks without it.

What is the advantage of the redundant port mode?

In redundant mode, both network ports carry identical audio. If the primary link fails, the secondary takes over instantly with no audio interruption — a critical feature for live events and broadcast.

Can the M-DANTE-A be used for multitrack recording without a dedicated audio interface?

Yes. Any computer running Dante Virtual Soundcard or equipped with a Dante AVIO adapter can receive up to 64 channels directly from the network, eliminating the need for additional interface hardware.

Is professional installation required for this module?

This is a factory-fit option card. Installation should be performed by an authorized Allen & Heath service center or qualified technician to maintain warranty compliance.
