Allen & Heath AH-DLC15-RK19 – dLive C1500 19" Rackmount Kit

Product Overview

The Allen & Heath AH-DLC15-RK19 is the manufacturer-specified 19" rackmount kit for the dLive C1500 surface, enabling horizontal installation into standard EIA-standard mobile racks, touring cases, and permanent AV equipment rooms. Engineered to match the C1500's dimensions precisely, the kit provides a secure, vibration-resistant mounting solution that protects the console during transport and maintains professional aesthetics in installed environments. The bracket set mounts the C1500 flush within a rack frame without modifying the console, preserving the warranty and resale value of the surface. For integrators deploying dLive systems in fixed installations or touring rigs, the DLC15-RK19 is the correct and only Allen & Heath-approved rack solution for this console.

Product Description

The dLive C1500 is Allen & Heath's entry-point into the dLive digital mixing platform, offering 12 faders, full dLive processing, and compatibility with all dLive MixRacks and I/O expanders. While the C1500 is designed for use on a tabletop or in a custom-built position, many permanent and touring deployments require the console to sit in a standard 19" rack — and the AH-DLC15-RK19 is the hardware that makes this possible.

The bracket assembly is manufactured to Allen & Heath's production tolerances, ensuring the C1500 sits level within the rack with all rear panel connectors accessible. This matters in environments where XLR, AES, and network connections must remain accessible without removing the console — a common requirement in fixed-installation broadcast studios, houses of worship AV rooms, and corporate AV control rooms.

Mobile touring deployments benefit from the secure mechanical retention that the DLC15-RK19 provides. Vibration from vehicle transport, repeated setup and teardown, and accidental impacts are all better managed when the console is secured in a proper rack mount versus resting on a stage lip or foam padding. The rackmount kit integrates with standard rack case accessories such as rack drawers, shock-mount frames, and cable management panels.

Installation is straightforward: the bracket attaches to the C1500 using the provided hardware and the assembly then inserts into any 19" EIA-standard rack. No drilling, modification to the console, or custom fabrication is required. AV integrators handling large dLive deployments should consider stocking this kit alongside the C1500 as a default line item in system designs that include any form of rack infrastructure.

Key Features

• Manufacturer-specified fit — designed and supplied by Allen & Heath to match C1500 dimensions precisely
• 19" EIA-standard rack compatibility — fits any standard touring rack case, equipment rack, or server cabinet
• Horizontal mounting orientation — mounts the C1500 surface horizontally for operator access in rack environments
• Non-destructive installation — attaches to existing C1500 hardware points without modification to the console
• Full rear-panel access — all XLR, network, and power connections remain accessible in the rack
• Vibration-resistant in transport — secures the console in mobile rack cases for touring or event production deployment
• Professional aesthetics — presents a clean, finished appearance appropriate for permanent installation environments

Typical Applications

• dLive C1500 rack installation — primary application: any deployment where the C1500 must be mounted in a 19" rack rather than on a tabletop
• Commercial AV systems integration — fixed installation in broadcast control rooms, corporate AV rooms, and performance venues
• Touring and event production — secure the C1500 in a mobile rack case for transport and deployment at multiple venues
• House of worship AV rooms — rack-mount the C1500 in a dedicated sound booth or equipment room alongside amplifiers and signal processors
• Rental and staging companies — standardize the C1500 into a rack-based inventory system for consistent setup and teardown procedures

Technical Specifications

Frequently Asked Questions

Will the AH-DLC15-RK19 fit any other Allen & Heath dLive surface?

No. The DLC15-RK19 is specifically dimensioned for the dLive C1500. Other dLive surfaces (C2500, C3500, etc.) have different form factors and require their own rackmount kits.

Does the rackmount kit ship with all required hardware?

Yes. The kit includes the bracket assembly and all fasteners required to mount the C1500 into a standard 19" rack.

How many rack units does the C1500 occupy when rack-mounted?

The rack unit height is determined by the C1500's physical dimensions with the bracket attached. Consult the Allen & Heath C1500 datasheet or contact Creation Networks for the exact rack unit requirement before planning your rack layout.

Can I still access the C1500 touchscreen and faders when rack-mounted?

Yes. The horizontal mounting orientation keeps the surface controls — touchscreen, faders, and knobs — fully accessible from the front of the rack.

Is this kit required for warranty compliance?

Using manufacturer-supplied mounting hardware is strongly recommended. Third-party or improvised rack mounting solutions that stress the chassis could void warranty coverage for physical damage.

Is this suitable for a shock-mounted rack case?

Yes. The DLC15-RK19 installs the C1500 into the 19" rack space, which can then be placed in a shock-mounted rack case for additional vibration isolation during transport.
