Allen & Heath AH-AHM-16 16x16 Audio Matrix Processor with 8x8 I/O

Product Overview

The Allen & Heath AHM-16 is a professional 16x16 audio matrix processor engineered for installed sound applications including multi-zone audio distribution, paging, conferencing, and speaker processing across corporate, hospitality, education, and commercial AV environments. With 8x8 local analog I/O expandable to 128x128 through the system's I/O port, the AHM-16 provides the routing flexibility and DSP capability required for complex, permanently installed audio systems without the complexity of a full digital mixing console. Running on a 96kHz FPGA processing core for ultralow latency, it integrates with Allen & Heath remote controllers, Dante networking, and third-party control systems via GPIO and TCP/IP. The AHM-16 is the entry-level model in Allen & Heath's AHM range, making it the right starting point for boardrooms, conference centers, retail environments, and multi-room commercial AV installations requiring reliable, scalable matrix audio processing.

Product Description

The AHM-16 occupies a well-defined position in the commercial installed sound market: it is an audio matrix processor that provides the routing, processing, and control features demanded by professional AV installations, without the physical footprint or operational complexity of a full-format mixing console. Its 1U rack-mount form factor and included Phoenix connectors allow it to be installed cleanly in any standard equipment rack.

The processor delivers 16x16 matrix routing with 8x8 local analog I/O available on the front panel via Phoenix block connectors. Outputs are configurable as 16 mono or 8 stereo zones, providing the flexibility required for varying room layouts. For larger installations, the I/O expansion port scales the system to 128x128 using Allen & Heath's AudioRack expanders or Dante-based networking, enabling the AHM-16 to serve as the processing core of a distributed audio system across an entire building.

Sound management tools built into the AHM-16 include level control, muting, routing matrix programming, and speaker processing — all configurable through the Allen & Heath Architect software running on a connected PC or Mac. GPIO inputs and TCP/IP communication ports allow integration with third-party control systems including Crestron, AMX, and QSC platforms, making the AHM-16 a natural fit for any commercial AV environment where centralized control is a requirement.

The 96kHz FPGA processing core delivers ultralow latency across all audio paths, ensuring that paging announcements, conference audio, and background music distribution remain time-aligned and intelligible in all zones. Allen & Heath's remote controller ecosystem — including IP touch panels, the CC-10, and IP8 button controller — allows AHM-16 installations to be operated intuitively by non-technical end users, a critical requirement in corporate and hospitality environments.

Key Features

• 16x16 Matrix with 8x8 Local Analog I/O — Flexible routing for multi-zone audio distribution across up to 16 independent zones
• Expandable to 128x128 — I/O expansion port supports AudioRack expanders and Dante networking for large building-wide installations
• 96kHz FPGA Core — Ultralow latency processing ensures audio is time-aligned across all zones including paging and conferencing
• Configurable Outputs — 16 mono or 8 stereo output configurations to match room and zone layout requirements
• Third-Party Control Integration — GPIO and TCP/IP ports enable integration with Crestron, AMX, and industry-standard control systems
• Speaker Processing Built-In — Onboard DSP handles EQ, delay, crossover, and limiting for speaker management within the matrix
• Allen & Heath Remote Controller Compatible — Works with IP touch panels, CC-10, and IP series controllers for end-user operation
• 1U Rack Mount Form Factor — Compact chassis with Phoenix block connectors installs cleanly in any standard equipment rack
• Audio Distribution, Paging, and Conferencing — Single processor handles multiple installed sound functions simultaneously
• Dante Network Audio Support — Layer-2 and Dante transport protocols for flexible audio networking infrastructure

Typical Applications

• Corporate boardrooms and conference rooms requiring multi-zone audio distribution and conferencing integration
• Multi-zone commercial AV installations in office buildings and corporate campuses
• Hospitality venues including hotels, restaurants, and lobbies with paging and background music
• Education facilities requiring distributed audio with zone control and paging
• Retail environments with multi-zone background music and announcement systems
• Event spaces and multipurpose venues with reconfigurable audio zone routing
• House of worship overflow and lobby zone audio distribution

Technical Specifications

Frequently Asked Questions

What is the difference between the AHM-16 and AHM-32?

The AHM-16 provides a 16x16 matrix with 8x8 local I/O, while the AHM-32 offers a 32x32 matrix with 16x16 local I/O. The AHM-16 is the appropriate starting point for smaller to mid-size commercial installations, with expansion capability if the system grows.

Can the AHM-16 be integrated with Crestron or AMX control systems?

Yes. The AHM-16 supports TCP/IP and GPIO control, enabling integration with Crestron, AMX, QSC, and other industry-standard control platforms.

Does the AHM-16 support Dante audio networking?

Yes. The AHM-16 supports Dante as well as Allen & Heath's proprietary Layer-2 transport protocol for connecting AudioRack expanders and extending the system to 128x128.

What remote controllers are compatible with the AHM-16?

The AHM-16 is compatible with Allen & Heath's IP series touch panels, the CC-10 touch panel, IP8 button controller, and the Allen & Heath smartphone app. Third-party controllers are supported via TCP/IP.

How is the AHM-16 configured?

System configuration is performed using Allen & Heath Architect software on a connected PC or Mac. Scene programming, routing, and zone configuration can be saved and recalled.

Can the AHM-16 handle conferencing and paging simultaneously with background music?

Yes. The AHM-16's matrix routing and DSP architecture supports concurrent audio functions across independent zones, including background music, paging priority, and conferencing in separate areas.

Is the AHM-16 suitable for use in a house of worship?

Yes, for overflow, lobby, and ancillary zone distribution. For main sanctuary mixing, an Allen & Heath digital console such as the Qu or SQ series would be more appropriate.
