ZeeVee Z4KANLENCC3U ZyPer4K Single HDMI 2.0 and Analogue CatX Encoder USB

Product Overview

The ZeeVee Z4KANLENCC3U is a ZyPer4K SDVoE copper encoder that accepts HDMI 2.0 and legacy analog video inputs (component, composite, VGA, S-video) with USB 2.0 extension over a 10GbE copper network. Designed as an analog video AV-over-IP encoder with integrated KVM capability, it allows legacy and modern AV sources to be distributed across a ZyPer4K SDVoE network while also extending USB peripherals. The unit integrates with the ZyPer Management Platform for centralized routing, video wall, and multiview management.

Product Description

The Z4KANLENCC3U adds USB 2.0 extension to the Z4KANLENCC3 analog + HDMI encoder platform, making it the preferred choice when legacy source integration must be combined with KVM-over-IP functionality. It accepts HDMI 2.0 or analog inputs (component, composite, VGA, S-video) and encodes the selected signal for transmission over 10Gb Cat6a copper at distances up to 100 meters. The USB 2.0 port enables keyboard, mouse, and peripheral sharing across the SDVoE network from the encoder location. ZMP provides full routing, video wall (15x15), and multiview (up to 19 sources) management. HDCP 2.2 and AES-128 encryption are standard. RS-232 (9-pin D-sub, 115.2 kbps) and IR (3.5mm) pass-through support control system integration. Power draw is approximately 9W.

Key Features

• HDMI 2.0 + Analog Video Inputs — Integrates component, composite, VGA, and S-video sources into the ZyPer4K SDVoE network without external converters.
• USB 2.0 Extension — Extends USB peripherals from the source location across the SDVoE network for KVM-over-IP capability.
• 10GbE Copper (Cat6a to 100m) — Standard enterprise cabling for network connection.
• Video Wall: 15x15 — Large-format video wall support via ZMP.
• Multiview: 19 Sources — Flexible multi-source layouts including legacy analog sources.
• HDCP 2.2 + AES-128 — Content protection and encrypted transport.
• RS-232 & IR Pass-Through — Control system integration at the source location.
• ~9W Power Draw — Efficient for high-density encoder deployments.
• 3-Year Warranty — ZeeVee standard commercial coverage.

Typical Applications

• AV upgrades where legacy analog sources must integrate into SDVoE with KVM requirements
• Government and military installations with analog equipment and USB peripheral sharing needs
• Higher education AV systems mixing analog and HDMI sources with classroom USB control
• Control rooms requiring legacy video input encoding alongside USB peripheral extension
• Security and surveillance integrations with analog cameras and USB device management

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What is the difference between the Z4KANLENCC3 and Z4KANLENCC3U?

The Z4KANLENCC3U adds a single USB 2.0 port for peripheral extension over the SDVoE network. All video input, audio, control, and network specifications are identical to the Z4KANLENCC3.

Can legacy analog sources and HDMI be routed independently via ZMP?

Yes. ZMP treats the encoder as a single source endpoint. Input selection (HDMI vs. analog) is configured per encoder through ZMP or a connected control system.

Does USB extension require a matching USB decoder?

Yes. End-to-end USB extension requires USB-capable decoders. USB pass-through is configured and managed within ZMP.

Is a fiber version of this model available?

Yes. The Z4KANLENCF3U provides identical capabilities over 10Gb multimode fiber up to 300m.

How does the encoder handle upscaling of analog inputs?

The encoder transmits analog source signals at their native resolution; it does not upscale analog video to 4K. HDMI sources can achieve up to 4KP60 4:4:4.
