ViewSonic LS510WH-2 3,000 ANSI Lumens WXGA LED Projector - Discontinued
ViewSonic LS510WH-2 3,000 ANSI Lumens WXGA LED Projector - Discontinued is backordered and will ship as soon as it is back in stock.
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
ViewSonic LS510WH-2 3,000 ANSI Lumens WXGA LED Projector - Disconti...
Product Overview
The ViewSonic LS510WH-2 is a 3,000 ANSI lumen WXGA LED projector targeted at classrooms, training rooms, and conference spaces that require a low-maintenance, energy-efficient alternative to lamp-based projection. The mercury-free LED light source is rated at 30,000 hours — eliminating lamp replacement for the operational life of the installation — while consuming over 50% less power than comparable LCD projectors. An IP5X-sealed optical engine, 360° installation flexibility, and SuperColor+ technology covering 125% Rec.709 make it a practical and cost-effective choice for budget-conscious institutional AV deployments.
Product Description
The LS510WH-2 uses an LED light source rather than laser phosphor, which places it in a different category from ViewSonic's LS6xx and LS7xx laser series. LED technology provides instant on/off operation, consistent color temperature over the life of the source, and mercury-free disposal compliance — but at a lower absolute brightness ceiling (3,000 ANSI lumens) than laser equivalents. This positions the LS510WH-2 for moderately-lit rooms or controlled-light environments rather than fully ambient-lit large venues. WXGA (1280x800) resolution suits standard presentation and document workflows. SuperColor+ technology expands the color gamut to 125% of the Rec.709 standard, with HDR support adding dynamic range for video content. The IP5X-sealed optical engine protects against dust in classroom and retail environments where air quality varies. A 1.1x optical zoom and 1.3–1.56:1 throw ratio provide limited but adequate installation adjustment. The 360° projection capability supports floor, ceiling, and tilted installations. Connectivity is pragmatic: HDMI 1.4, USB-A (for power and media), RJ45 Ethernet for PJ-Link-based remote management, and RS-232 for serial control system integration. The 2W speaker is supplemental; external audio should be planned for rooms requiring adequate volume. At 5.8 lbs, it is among the lighter options in this category for easy ceiling mount handling.
Key Features
- 3,000 ANSI Lumens LED Light Source — 30,000-hour mercury-free LED; no lamp replacements, instant on/off.
- SuperColor+ (125% Rec.709) — Wide color gamut with HDR support for accurate, vivid image reproduction.
- IP5X Sealed Optical Engine — Dust-resistant for reliable 24/7 operation in variable air quality environments.
- WXGA 1280x800 Native Resolution — Native widescreen format for standard presentation and document content.
- 360° Projection + Vertical Keystone — Flexible installation orientation without geometric distortion.
- RJ45 Ethernet (PJ-Link) + RS-232 — Network and serial control system integration for managed AV deployments.
- Over 50% Power Reduction vs. LCD — Reduces operating costs in continuous-use institutional settings.
- 5.8 lbs Lightweight Chassis — Simplified single-person ceiling mount installation.
Typical Applications
- Classrooms and university lecture rooms requiring low-maintenance projection
- Corporate training rooms with controlled ambient lighting
- Conference rooms for standard presentation workflows
- Government spaces with energy efficiency and disposal compliance requirements
- Retail and digital signage in moderate ambient light
Technical Specifications
| Native Resolution | 1280 x 800 (WXGA) |
| Brightness | 3,000 ANSI Lumens |
| Contrast Ratio | 3,000,000:1 (dynamic) |
| Light Source | LED (mercury-free) |
| Light Source Life | 30,000 hours |
| Color Gamut | 125% Rec.709 (SuperColor+) |
| Throw Ratio | 1.3–1.56:1 |
| Optical Zoom | 1.1x |
| Projection Size | 30" – 300" |
| Optical Engine Seal | IP5X |
| Inputs | HDMI 1.4 (HDCP 1.4), USB-A 2.0, RJ45 Ethernet, 3.5mm Audio In, RS-232 |
| Audio Output | 3.5mm |
| Speaker | 2W x 1 |
| Dimensions (W x D x H) | 15.2 x 11.8 x 7.4" |
| Weight | 5.8 lbs |
Frequently Asked Questions
Q: What is the difference between the LS510WH-2 LED source and a laser projector like the LS630W?
A: The LS510WH-2 uses an LED light source; the LS630W uses laser phosphor. Both offer long life (30,000 hours) and no lamp replacement. Laser phosphor typically delivers higher absolute brightness (4,500 vs. 3,000 lumens) and is better suited for fully ambient-lit large rooms. LED provides more consistent color temperature and is adequate for controlled-light environments.
Q: Can the LS510WH-2 be used for 24/7 continuous digital signage?
A: Yes. The IP5X sealed optical engine and 30,000-hour LED source support continuous operation. Verify ventilation clearances per the installation guide for uninterrupted 24/7 use.
Q: Does it support network-based remote management?
A: Yes. RJ45 Ethernet with PJ-Link enables network monitoring and control. RS-232 is available for serial control system integration.
Q: What wireless display options are available?
A: The LS510WH-2 does not have built-in wireless. A wireless HDMI dongle powered from the USB-A port can enable wireless casting from supported devices.
Q: Is the 2W speaker sufficient for a classroom?
A: For small training rooms and personal setups it is adequate. For standard-sized classrooms, external audio via the 3.5mm output to a PA or powered speaker is recommended.
Q: How does the 125% Rec.709 color gamut affect presentation content?
A: For typical business presentation slides and documents, it produces accurate, vivid colors. For video content mastered to Rec.709, enable the appropriate color mode in the OSD to avoid oversaturation.
Replacement Product: LS630W
