TOA U-01F – Unbalanced XLR Line Input Module

Product Overview

The TOA U-01F is a plug-in unbalanced line input module with a female XLR connector for TOA 900 Series mixer-amplifiers and compatible chassis. It brings line-level sources such as tuners, media players, mixers, and sound cards into a commercial distributed-audio system through a locking XLR. A front gain control sets level to match the other inputs in the host unit.

Product Description

The U-01F installs into an open module slot on a TOA 900 Series host and draws 24 V DC from the main frame. It is intended for adjacent line-level sources located within roughly 15 feet of the host, where an unbalanced connection on a secure XLR is preferred. The female XLR-3-31 equivalent connector locks in place, which is useful where a media feed must not be accidentally unplugged. With a 220 kΩ input impedance, the module bridges most consumer and prosumer line outputs without loading them. Gain is adjustable from -30 dB to 0 dB so the source matches microphones and other inputs in the same chassis. Frequency response runs 20 Hz to 20 kHz with low distortion, keeping music and program audio full-range. The module is a clean way to add a locking line input to a fixed-install background-music or paging system. For sources that benefit from a secured XLR connection, the U-01F is the matched 900 Series input.

Key Features

• Locking XLR input — The female XLR connector secures a line feed against accidental disconnection.
• 220 kΩ unbalanced input — The high impedance bridges consumer and prosumer line sources without loading them.
• Front-panel gain control — A -30 dB to 0 dB range matches the source to other inputs in the chassis.
• Frame-powered design — The module draws 24 V DC from the host, so no external supply is needed.
• Low-distortion path — A 20 Hz to 20 kHz response with 0.05 % distortion keeps audio clean.
• 900 Series fit — The module installs in standard TOA 900 Series host slots.

Technical Specifications

Specifications per the TOA datasheet.
